Assembly
100%

318-5935 LINES GP-AUXILIARY HYDRAULIC -STICK, HIGH PRESSURES/N SZT1-UP

Group No: 318-5935 · Commonality
Part NumberPart NameQty
7I74201 HOSE AS2
17379162 CLAMP-HALF8
26232333 TUBE AS2
38924074 VALVE GP-MANUAL (AUXILIARY, SHUTOFF, 2-WAY FLOW)2
1P37045 SEAL-RECTANGULAR8
1P57676 FLANGE-HALF12
8C89927 BOLT-LOCKING (M12X1.75X30-MM)8
8T41218 WASHER-HARD (11X21X2.5-MM THK)4
8T49569 BOLT (M12X1.75X35-MM)8
8T419410 BOLT (M12X1.75X50-MM)16
8T422311 WASHER-HARD (13.5X25.5X3-MM THK)32
8T668512 BOLT (M10X1.5X110-MM)4
5P004813 COVER2
8T418414 BOLT (M12X1.75X45-MM)8
