Assembly
100%

321-0141 LINES GP-AUXILIARY HYDRAULIC -STICK, MEDIUM PRESSURES/N SZT1-UP

Group No: 321-0141 · Commonality
Part NumberPart NameQty
6C67601 MANIFOLD2
18799812 SUPPORT AS2
19723843 SUPPORT AS2
20270014 CLIP8
25014405 ADAPTER AS2
3K0360SEAL-O-RING1
7X3164ADAPTER-SWIVEL1
25364556 TUBE AS2
25365547 HOSE AS2
20270028 PLATE2
3E80049 BOLT (M12X1.75X45-MM)(LOCKING)8
6V839810 SEAL-O-RING4
7X254311 BOLT (M10X1.5X120-MM)4
8T412112 WASHER-HARD (11X21X2.5-MM THK)4
8T413913 BOLT (M12X1.75X30-MM)8
8T418514 BOLT (M10X1.5X50-MM)4
8T422315 WASHER-HARD (13.5X25.5X3-MM THK)8
8T797116 WASHER-HARD (13.5X25.5X5-MM THK)8
8T413617 BOLT (M10X1.5X25-MM)4
8T413918 BOLT (M12X1.75X30-MM)8
8T422319 WASHER-HARD (13.5X25.5X3-MM THK)8
