System And Components
555-3720 LINES GP-WATERAN ATTACHMENT
Group No: 555-3720
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S1889 | 1 GASKET | 2 | |
| 5M2894 | 2 WASHER-HARD (10.2X18.5X2.5-MM THK) | 12 | |
| 7C9052 | 3 ELBOW | 1 | |
| 9X6138 | 4 PLUG-PIPE | 2 | |
| 1466785 | 5 TUBE | 1 | |
| 1653931 | 6 BOLT (3/8-16X1.75-IN) | 6 | |
| 0S1588 | 7 BOLT (3/8-16X1.25-IN) | 2 | |
| 0S1594 | 8 BOLT (3/8-16X1-IN) | 4 | |
| 0S1608 | 9 BOLT (3/8-16X3.75-IN) | 2 | |
| 0T0065 | 10 BOLT (3/8-16X3.5-IN) | 2 | |
| 1714358 | 11 SEAL-O-RING | 2 | |
| 2N8306 | 12 ELBOW-OUTLET | 2 | |
| 3535124 | 13 PLUG AS | 1 | |
| 6V3250 | SEAL-O-RING | 1 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 3B1915 | 14 BOLT (3/8-16X1.375-IN) | 4 | |
| 4L3833 | 15 GASKET | 2 | |
| 6B9763 | 16 VALVE-DRAIN | 1 | |
| 7W9219 | 17 ELBOW | 1 | |
| 8N0450 | 18 RETAINER | 4 | |
| 8N0453 | 19 RING-RETAINING | 2 | |
| 8T6765 | 20 PLUG-PIPE (1/4-18-THD) | 2 | |
| 9S8752 | 21 NUT-FULL (3/8-16-THD) | 8 | |
| 9Y0068 | 22 FLANGE | 1 | |
| 9Y1263 | 23 FLANGE | 1 |
