System And Components
205-6559 RADIATOR GPS/N N471-UP
Group No: 205-6559
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3K3318 | 1 BOLT (3/4-10X4.25-IN) | 2 | |
| 6L2282 | 2 PLUG-PIPE | 4 | |
| 7L2505 | 3 PLUG-PIPE | 4 | |
| 9Y5995 | 4 PLATE-WASHER | 4 | |
| 9Y6003 | 5 BRACKET-CORNER | 4 | |
| 9Y6004 | 6 BRACKET-CORNER | 4 | |
| 9Y6005 | 7 BRACKET AS-GUARD | 8 | |
| 9Y6007 | 8 WASHER-FLANGE | 26 | |
| 1102991 | 9 STRAP-COREWASHER | 4 | |
| 1102996 | 10 BRACKET | 1 | |
| 1103006 | 11 BRACKET | 1 | |
| 1239314 | 12 PLATE-WASHER | 2 | |
| 1239316 | 13 GAUGE-SIGHT (COOLANT LEVEL) | 2 | |
| 1239320 | 14 BRACKET | 4 | |
| 1239362 | 15 CAP-FILLER (7-PSI) | 2 | |
| 1256287 | 16 GASKET | 2 | |
| 1260559 | 17 BOLT (5/16-18X1.25-IN) | 26 | |
| 1278135 | 18 GASKET | 2 | |
| 1278136 | 19 PLATE | 8 | |
| 2056565 | 20 CORE | 1 | |
| 2056588 | 21 PLATE | 1 | |
| 2056591 | 22 SHROUD (TOP) | 2 | |
| 2056592 | 23 SHROUD (LEFT) | 1 | |
| 2056593 | 24 SHROUD (RIGHT) | 1 | |
| 2056594 | 25 GUARD | 1 | |
| 2056595 | 26 GUARD | 1 | |
| 2056598 | 27 BRACKET | 2 | |
| 2056601 | 28 BRACE | 2 | |
| 2056603 | 29 BRACKET | 3 | |
| 2056621 | 30 LINES GP-WATER | 1 | |
| 2056622 | 31 LINES GP-WATER | 1 | |
| 2056904 | 32 GUARD AS-FAN | 2 | |
| 2057636 | 33 SUPPORT | 2 | |
| 2093057 | 34 BRACKET | 2 | |
| 2248493 | 35 TANK-COOLANT | 1 | |
| 2248495 | 36 TANK-COOLANT | 1 | |
| 6V8182 | 37 NUT (3/4-10-THD) | 4 | |
| 7X0365 | 38 BOLT (3/4-10X1.5-IN) | 2 | |
| 7X0582 | 39 WASHER-HARD (20X44.5X6-MM THK) | 2 | |
| 8T4994 | 40 WASHER-HARD (20X36.5X3.5-MM THK) | 2 |
