System And Components
353-3709 BOX GP-EXTENSION TERMINALS/N 6R91-UP
Group No: 353-3709
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1253295 | 1 SCREW-PAN HEAD (M2.5X0.45X12-MM) | 4 | |
| 1550935 | 2 FILM-INFORMATION (ELECTRIC COMPONENT IDENTIFY) | 1 | |
| 1609674 | 3 SEAL | 1 | |
| 1690250 | 4 PANEL GP-CONTROL (DC) | 1 | |
| 1694449 | 5 HARNESS AS-BOX (70-PIN) | 1 | |
| 6V5817 | CONDUIT-FLEXIBLE (26.1-MM ID, SPLIT)(1-M) | ||
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 106 | |
| 8T8737 | PLUG-SEAL | 1 | |
| 9X0141 | PLUG AS-CONNECTOR (40-PIN) | 1 | |
| 3E4367 | RING-RETAINING | 1 | |
| 3E8557 | BOLT (M5X0.8X39.37-MM) | 1 | |
| 9X3490 | SEAL-CONNECTOR (40-PIN) | 2 | |
| 9X4391 | PLUG AS-CONNECTOR (70-PIN) | 1 | |
| 3E4367 | RING-RETAINING | 1 | |
| 3E8557 | BOLT (M5X0.8X39.37-MM) | 1 | |
| 9X5615 | SEAL (INTERFACE, 70-PIN) | 2 | |
| 9X7147 | PLUG AS-CONNECTOR (40-PIN) | 1 | |
| 3E4367 | RING-RETAINING | 1 | |
| 3E8557 | BOLT (M5X0.8X39.37-MM) | 1 | |
| 9X3490 | SEAL-CONNECTOR (40-PIN) | 2 | |
| 1699012 | 6 WASHER-HARD (2.7X6X0.5-MM THK) | 4 | |
| 1699016 | 7 NUT (M2.5X0.45-THD) | 4 | |
| 1952637 | 8 SCREW (8-32X0.5-IN) | 2 | |
| 1996173 | 9 BAR GP-GROUND | 1 | |
| 1996485 | 10 HARNESS AS-BOX (SERVICE CONNECTOR) | 1 | |
| 1S9593 | STRAP-CABLE | 9 | |
| 8C6354 | CAP-RECEPTACLE (ET CONNECTOR) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 6 | |
| 1093038 | END-WIRE (16-GA) | 6 | |
| 1282312 | CONNECTOR | 1 | |
| 2008376 | 11 FILM-INFORMATION (REPLACEMENT FUSE CHART) | 1 | |
| 2028729 | 12 FILM-INFORMATION (OPTIONAL GROUND CONDUCTORS) | 1 | |
| 2071781 | 13 PANEL GP-ELECTRONIC | 1 | |
| 2211728 | 14 HARNESS AS-BOX (AC) | 1 | |
| 1S9593 | STRAP-CABLE | 12 | |
| 3S2093 | STRAP-CABLE | 5 | |
| 6K0806 | STRAP-CABLE | 30 | |
| 8L8413 | STRAP-CABLE (WHITE) | 4 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 11 | |
| 8T8737 | PLUG-SEAL | 29 | |
| 9X1343 | RECEPTACLE AS-CONNECTOR (40-PIN) | 1 | |
| 1093038 | END-WIRE (16-GA) | 21 | |
| 1138961 | END-WIRE (10-GA) | 2 | |
| 1311474 | TERMINAL AS | 3 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(3-CM) | ||
| 1311502 | TERMINAL AS | 3 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(3-CM) | ||
| 2211729 | 15 HARNESS AS-BOX (DC) | 1 | |
| 1S9593 | STRAP-CABLE | 5 | |
| 3S2093 | STRAP-CABLE | 8 | |
| 6K0806 | STRAP-CABLE | 14 | |
| 8L8413 | STRAP-CABLE (WHITE) | 8 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 32 | |
| 8T8737 | PLUG-SEAL | 8 | |
| 9X7148 | RECEPTACLE AS-CONNECTOR (40-PIN) | 1 | |
| 1093038 | END-WIRE (16-GA) | 44 | |
| 1311502 | TERMINAL AS | 4 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(3-CM) | ||
| 2372925 | 16 STRIP GP-TERMINAL | 1 | |
| 3533710 | 17 BOX AS | 1 | |
| 3E4304 | INSERT-THREADED (M6X1-THD) | 25 | |
| 1803748 | INSERT-THREADED (M8X1.25-THD) | 24 | |
| 1977426 | INSERT-THREADED (M4X0.7-THD) | 9 | |
| 2358354 | FASTENER | 4 | |
| 0618844 | 18 GROMMET | 2 | |
| 2D6235 | 19 LOCKNUT (1/4-20-THD) | 2 | |
| 3B4501 | 20 LOCKWASHER | 11 | |
| 4B4274 | 21 WASHER (5.5X13X1.2-MM THK) | 2 | |
| 5C8312 | 22 NUT (M4X0.7-THD) | 11 | |
| 5C9553 | 23 BOLT (M6X1X16-MM) | 8 | |
| 6V9491 | 24 SCREW-MACHINE (M4X0.7X20-MM) | 8 | |
| 8C6433 | 25 SCREW (M6X1X30-MM) | 8 | |
| 9X8256 | 26 WASHER (6.6X12X2-MM THK) | 16 | |
| 2177165 | 27 DUCT-WIRE (290-MM) | ||
| 3E6600 | 28 SEAL (142-CM) | ||
| 3E6600 | 28A SEAL (155-CM) | ||
| 3E6600 | 28B SEAL (54-CM) |
