System And Components
560-8073 MOUNTING GP-ALTERNATOR & COMPRPART OF 524-4584 ENGINE AR-PRIMARY
Group No: 560-8073
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1137584 | 1 BOLT (M10X1.5X110-MM) | 2 | |
| 1232899 | 2 BOLT (M10X1.5X40-MM) | 2 | |
| 3849992 | 3 SEAL-O-RING | 1 | |
| 5222814 | 4 BOLT-FLANGE HEAD (M10X1.5X27-MM) | 3 | |
| 5222817 | 5 NUT-FLANGE (M10X1.5-THD) | 1 | |
| 5222820 | 6 BOLT-FLANGE HEAD (M8X1.25X95-MM) | 4 | |
| 5222897 | 7 BOLT-FLANGE HEAD (M12X1.75X80-MM) | 1 | |
| 5222898 | 8 TENSIONER-BELT | 1 | |
| 5222899 | 9 BOLT-FLANGE HEAD (M10X1.5X65-MM) | 1 | |
| 5222932 | 10 BUSHING | 1 | |
| 5222936 | 11 PULLEY-IDLER | 1 | |
| 5223087 | 12 VALVE (COOLANT) | 1 | |
| 5223088 | 13 SEAL-O-RING | 1 | |
| 5223091 | 14 SEAL-O-RING | 1 | |
| 5223093 | 15 NUT (M12X1.75-THD)(M12X1.75-THD) | 1 | |
| 5608074 | 16 ALTERNATOR GP-CHARGING | 1 | |
| 5608084 | 17 COMPRESSOR GP-REFRIGERANT | 1 | |
| 5913865 | COVER AS-COMPRESSOR | 1 | |
| 1404681 | BOLT (M6X1X20-MM) | 3 | |
| 5608087 | 18 BELT-SERPENTINE | 1 | |
| 5630144 | 19 BRACKET | 1 | |
| 5630145 | 20 BRACKET | 1 | |
| 5647714 | 21 ELBOW | 1 | |
| 8T5001 | 22 BOLT (M12X1.75X130-MM) | 1 |
