System And Components
8N-4252 PUMP GP-WATERS/N 37Y373-UP
Group No: 8N-4252
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0L1351 | 1 BOLT (3/8-16X0.875-IN) | 2 | |
| 8N5928 | 2 GASKET | 1 | |
| 6N9312 | 3 SEAL GP-PUMP | 1 | |
| 1B3867 | 4 BALL BEARING | 1 | |
| 5M2894 | 5 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 8H9520 | 6 SEAL-LIP TYPE | 1 | |
| 1K6985 | 7 RING-RETAINING | 1 | |
| 5P0076 | 8 BOLT-12 POINT HEAD (3/8-16X1.5-IN) | 1 | |
| 6H3957 | 9 BALL BEARING | 1 | |
| 8N2626 | 10 GEAR AS (40 TEETH) | 1 | |
| 2L5893 | 11 PIN-SPRING | 2 | |
| 5F3106 | 12 SEAL-O-RING | 1 | |
| 5M6213 | 13 PLUG-PIPE (1/4-18-THD) | 1 | |
| 7N6366 | 14 HOUSING-PUMP | 1 | |
| 0T0055 | 15 BOLT (3/8-16X4.25-IN) | 2 | |
| 8N5929 | 16 COVER-WATER PUMP | 1 | |
| 7N5910 | 17 IMPELLER-PUMP | 1 | |
| 4L6454 | 18 BOLT (3/8-16X1-IN) | 1 | |
| 9M6527 | WASHER-HARD (10.2X25.5X5-MM THK) | 1 | |
| 7N5899 | 19 SHAFT-WATER PUMP | 1 | |
| 3B4506 | 20 LOCKWASHER | 1 | |
| 1W7055 | KIT-PUMP REBUILD | 1 |
