System And Components
7N-2375 GOVERNOR GPPART OF 8N-4920 CONVERSION AR-ENGINE
Group No: 7N-2375
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8L8883 | 1 SHAFT | 1 | |
| 9S4671 | 2 SEAL-LIP TYPE | 1 | |
| 2N2168 | 3 SCREW-ADJUSTMENT (HIGH IDLE) | 1 | |
| 2P8737 | 4 HOUSING AS-GOVERNOR | 1 | |
| 9S0798 | 5 BUSHING | 1 | |
| 8S0134 | 6 BUSHING | 1 | |
| 4F4585 | 7 PLUG-CORE | 1 | |
| 8M8403 | 8 SPRING-GUIDE | 1 | |
| 4N4881 | 9 PLUG | 2 | |
| 7D5473 | 10 BOLT-SOCKET HEAD (8-32X0.75-IN) | 1 | |
| 7N1651 | 11 COLLAR-LOAD STOP | 1 | |
| 8M8739 | 12 BOLT-LOAD STOP | 1 | |
| 8H9181 | 13 SPRING-BUMPER | 1 | |
| 6N3504 | 14 SEAT-GOVERNOR SPRING | 1 | |
| 9M3160 | 15 SPRING | 1 | |
| 6N8629 | 16 SEAT-SPRING | 1 | |
| 9M6302 | 17 WASHER-SPECIAL | 2 | |
| 4N3887 | 18 RING-RETAINING | 1 | |
| 2S0007 | 19 SLEEVE-PILOT | 1 | |
| 3K0810 | 20 RING-LOCK | 1 | |
| 7M7219 | 21 BEARING-THRUST | 1 | |
| 7M7193 | 22 RACE-THRUST BEARING | 2 | |
| 2P8630 | 23 DOWEL | 1 | |
| 9M6303 | 24 SPRING | 1 | |
| 2N0478 | 25 WEIGHT AS-GOVERNOR | 1 | |
| 2N0477 | WEIGHT | 2 | |
| 1S5440 | 26 DOWEL | 2 | |
| 5J5314 | 27 BOLT (5/16-18X1.5-IN) | 1 | |
| 1H5514 | 28 BOLT (5/16-18X1.625-IN) | 3 | |
| 9S5393 | 29 PLUG | 1 | |
| 2P8763 | GASKET | 1 | |
| 2B2695 | 30 BOLT (5/16-18X0.875-IN) | 1 | |
| 7N7163 | 31 COVER | 1 | |
| 9S4673 | 32 BAND AS-LEVER | 1 | |
| 9F6580 | 33 BOLT (1/4-20X1.125-IN) | 1 | |
| 4B9747 | WASHER (0.266X0.375X0.031-IN THK) | 1 | |
| 5L8992 | 34 COVER-ADJUSTMENT | 1 | |
| 5L8991 | GASKET-COVER | 1 | |
| 0S1617 | 35 BOLT (5/16-18X0.75-IN) | 1 | |
| 9S4466 | 36 LEVER AS-CONTROL | 1 | |
| 9S4468 | 37 BOLT-SPECIAL | 1 | |
| 2F4159 | LOCKNUT | 1 | |
| 7B8105 | 38 RING-LOCK | 1 | |
| 6N9339 | 39 GASKET-GOVERNOR HOUSING | 1 | |
| 1B7182 | 40 BOLT (5/16-18X1.25-IN) | 1 | |
| 0S1615 | 41 BOLT (1/4-20X0.75-IN) | 3 | |
| 9M6293 | 42 LOCK-CYLINDER | 1 | |
| 2P8725 | 43 PISTON AS | 1 | |
| 5P9757 | 44 SEAL-O-RING | 1 | |
| 2P8697 | 45 GASKET | 1 | |
| 1H5514 | 46 BOLT (5/16-18X1.625-IN) | 4 |
