System And Components
7N-4313 DRIVE GP-MAGNETOS/N 37Y1852-2053; 37Y2113-UP
Group No: 7N-4313
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1B4203 | 1 NUT-FULL (3/8-24-THD) | 3 | |
| 5M2894 | 2 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 2H3934 | 3 SEAL-O-RING | 1 | |
| 1C2251 | 4 BOLT (3/8-16X1.87-IN) | 1 | |
| 3J7352 | 5 CONNECTOR | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 7N6202 | 6 TUBE AS | 1 | |
| 0T0573 | 7 BOLT (3/8-16X2.75-IN) | 1 | |
| 1D4717 | NUT (3/8-16-THD) | 1 | |
| 8L6557 | 8 CONNECTOR | 1 | |
| 7N2997 | 9 HOUSING AS | 1 | |
| 6F0984 | 10 DOWEL | 2 | |
| 2A3348 | 11 DOWEL | 2 | |
| 7N2996 | 12 SHAFT | 1 | |
| 1S9848 | 13 BUSHING | 1 | |
| 1S7371 | 14 BEARING | 1 | |
| 4N2954 | 15 SLEEVE-CAMSHAFT | 1 | |
| 7N2589 | 16 GEAR AS-IDLER (24-TEETH) | 1 | |
| 7L5774 | BEARING | 1 | |
| 7N2998 | 17 ADAPTER AS | 1 | |
| 7N7239 | 18 BUSHING-TERMINAL | 1 | |
| 8M8356 | 19 BEARING | 1 | |
| 0L1351 | 20 BOLT (3/8-16X0.875-IN) | 4 | |
| 4F7957 | 21 BOLT (1/4-20X0.875-IN) | 2 | |
| 5P0537 | WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 9B0459 | 22 COVER | 1 | |
| 2K3967 | GASKET | 1 | |
| 8M1051 | 23 SEAL | 1 | |
| 7N2588 | 24 SHAFT AS | 1 | |
| 7N2995 | 25 GASKET | 1 |
