System And Components
2W-4873 IGNITION GP-GAS ENGINES/N 37Y373-UP
Group No: 2W-4873
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7W2479 | 1 WIRE AS-PLUG | 4 | |
| 2W3747 | 2 TRANSFORMER AS | 4 | |
| 2N2839 | 3 PLUG AS-SPARK | 4 | |
| 1083515 | GASKET-PLUG | 1 | |
| 8T6767 | 4 PLUG-PIPE (3/8-18-THD) | 1 | |
| 8M8157 | 5 SEAL-O-RING | 4 | |
| 3288383 | 6 MAGNETO GP | 1 | |
| 6L5270 | 7 GASKET-MAGNETO | 1 | |
| 3B1915 | 8 BOLT (3/8-16X1.375-IN) | 1 | |
| 5M2894 | 9 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 2B2695 | 10 BOLT (5/16-18X0.875-IN) | 8 | |
| 7N2587 | 11 GEAR GP-MAGNETO DRIVE (14-TEETH) | 1 | |
| 7B3235 | 12 BOLT (1/2-13X1.375-IN) | 1 | |
| 8T6764 | 13 PLUG-PIPE (1/8-27-THD) | 1 | |
| 0S1619 | 14 BOLT (3/8-16X3-IN) | 1 | |
| 2P3850 | 15 ADAPTER-LINES | 1 | |
| 8M5248 | 16 SEAL-O-RING | 1 | |
| 8M5253 | 17 SEAL-O-RING | 1 | |
| 5P8245 | 18 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 6V3964 | 19 WASHER-HARD (8.8X25.5X5-MM THK) | 8 | |
| 4P7581 | 20 CLIP (LADDER) | 3 | |
| 9X6772 | 21 STRAP-CABLE | 3 | |
| 6I2763 | 22 HARNESS AS-ENGINE (IGNITION) | 1 | |
| 3E6493 | PLUG AS-CONNECTOR | 1 | |
| 5P1476 | TERMINAL-FORK (14-GA TO 16-GA, NO. 10 SCREW) | 4 | |
| 5P1478 | TERMINAL-FORK (10-GA TO 12-GA, NO. 10 SCREW) | 4 | |
| 2L8078 | TERMINAL-RING (14-GA TO 16-GA, 5/16-IN SCREW) | 3 | |
| 2L8076 | TERMINAL-RING (14-GA TO 16-GA, NO. 10 SCREW) | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N9738 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 9G3695 | PLUG-SEAL | 1 | |
| 9X6458 | 24 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 0S1594 | 25 BOLT (3/8-16X1-IN) | 1 | |
| 5P6025 | 26 LOCKWIRE (0.1-M) | ||
| 8S8158 | 27 SEAL-WIRE | 1 |
