System And Components
9Y-6490 IGNITION GP-GAS ENGINEPART OF 8N-4920 CONVERSION AR-ENGINE
Group No: 9Y-6490
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1594 | 1 BOLT (3/8-16X1-IN) | 1 | |
| 4P7581 | 2 CLIP (LADDER) | 3 | |
| 7W2479 | 3 WIRE AS-PLUG | 4 | |
| 8T6767 | 4 PLUG-PIPE (3/8-18-THD) | 1 | |
| 8M8157 | 5 SEAL-O-RING | 4 | |
| 5P8245 | 6 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 6I2611 | 7 MAGNETO GP | 1 | |
| 6L5270 | 8 GASKET-MAGNETO | 1 | |
| 6I2763 | 9 HARNESS AS-ENGINE (IGNITION) | 1 | |
| 3E6493 | PLUG AS-CONNECTOR | 1 | |
| 7N9738 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 3B1915 | 10 BOLT (3/8-16X1.375-IN) | 1 | |
| 2W3747 | 11 TRANSFORMER AS | 4 | |
| 6V3964 | 13 WASHER-HARD (8.8X25.5X5-MM THK) | 8 | |
| 2B2695 | 14 BOLT (5/16-18X0.875-IN) | 8 | |
| 9X6458 | 15 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 9X6772 | 16 STRAP-CABLE | 3 | |
| 5M2894 | 17 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 7N2587 | 18 GEAR GP-MAGNETO DRIVE (14-TEETH) | 1 | |
| 7B3235 | 19 BOLT (1/2-13X1.375-IN) | 1 | |
| 8T6764 | 20 PLUG-PIPE (1/8-27-THD) | 1 | |
| 0S1619 | 21 BOLT (3/8-16X3-IN) | 1 | |
| 2P3850 | 22 ADAPTER-LINES | 1 | |
| 8M5248 | 23 SEAL-O-RING | 1 | |
| 8M5253 | 24 SEAL-O-RING | 1 | |
| 2N2839 | 25 PLUG AS-SPARK | 4 | |
| 1083515 | GASKET-PLUG | 1 | |
| 1H7339 | 26 SEAL-O-RING | 1 | |
| 9S8752 | 27 NUT-FULL (3/8-16-THD) | 1 | |
| 4P1650 | 28 COVER | 1 |
