System And Components
8N-5825 PANEL GP-INSTRUMENTPART OF 8N-4920 CONVERSION AR-ENGINE
Group No: 8N-5825
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6K1972 | 1 ELBOW-FLARED | 1 | |
| 7N9042 | 2 TUBE AS | 1 | |
| 4B0418 | 3 CLIP (LOOP) | 2 | |
| 4B6029 | 4 GROMMET | 1 | |
| 3N7229 | 5 HOSE AS (40.6CM) | 1 | |
| 8L6557 | 6 CONNECTOR | 1 | |
| 5L2574 | 7 PANEL AS-INSTRUMENT | 1 | |
| 6L2308 | 8 SWITCH-SNAP (RESET) | 1 | |
| 6L2309 | 9 SWITCH-STOP (ENGINE) | 1 | |
| 6L2310 | 10 GAUGE-OIL PRESSURE | 1 | |
| 6L2311 | 11 GAUGE-WATER TEMPERATURE | 1 | |
| 2L8077 | 12 TERMINAL-RING (14-GA TO 16-GA, 1/4-IN SCREW) | 1 | |
| 7H4155 | 13 MOUNT-FLEXIBLE | 4 | |
| 2N2258 | 14 RIVET-POP | 8 | |
| 7B2742 | 15 BOLT (1/4-20X1.25-IN) | 4 | |
| 1B4330 | 16 NUT (1/4-20-THD) | 6 | |
| 5P0537 | WASHER-HARD (7.2X14.5X2-MM THK) | 6 | |
| 2L8074 | 17 TERMINAL-RING (14-GA TO 16-GA, NO. 6 SCREW) | 1 | |
| 5P5624 | 18 WIRE (14-GA, BLACK) | ||
| 2L6094 | 19 ELBOW | 1 | |
| 7N6369 | 20 BRACE-PANEL | 2 | |
| 0S1615 | 21 BOLT (1/4-20X0.75-IN) | 2 | |
| 7N3001 | 22 PLATE-PANEL MOUNTING | 1 | |
| 2H3755 | 23 BOLT (5/16-18X0.43-IN) | 2 | |
| 9M1974 | 24 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 8F2396 | 25 GROMMET | 1 | |
| 1C0569 | 26 BOLT (5/16-18X0.5-IN) | 1 | |
| 6H6699 | 27 ADAPTER (HEAT INDICATOR) | 1 |
