Assembly
100%

7W-9700 IGNITION GP-GAS ENGINES/N 6NB1-UP

Group No: 7W-9700
Part NumberPart NameQty
7W84131 BRACKET2
1H55142 BOLT (5/16-18X1.625-IN)6
9M19743 WASHER-HARD (8.8X16X2-MM THK)22
1C05694 BOLT (5/16-18X0.5-IN)16
1B27905 BOLT (5/16-18X1.375-IN)2
9M1974WASHER-HARD (8.8X16X2-MM THK)2
8L5449SPACER (0.375X0.75X0.69-IN THK)2
1B27906 BOLT (5/16-18X1.375-IN)2
9M19747 WASHER-HARD (8.8X16X2-MM THK)2
8L54498 SPACER (0.375X0.75X0.69-IN THK)2
2W37439 MAGNETO GP1
1B279010 BOLT (5/16-18X1.375-IN)4
9M197411 WASHER-HARD (8.8X16X2-MM THK)4
8L544912 SPACER (0.375X0.75X0.69-IN THK)4
2W374713 TRANSFORMER AS8
7W854214 WIRE AS-PLUG8
7E0080BOOT1
7E007915 SEAL8
0T006516 BOLT (3/8-16X3.5-IN)2
5M289417 WASHER-HARD (10.2X18.5X2.5-MM THK)4
2N283918 PLUG AS-SPARK8
6L527019 GASKET-MAGNETO1
1A202920 BOLT (3/8-16X1.125-IN)2
7W982421 HARNESS AS-ENGINE (IGNITION)1
5P6627LOCKWIRE
5M621322 PLUG-PIPE (1/4-18-THD)1
