System And Components
163-6148 IGNITION GP-GAS ENGINES/N 7DB1-UP
Group No: 163-6148
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1636108 | 1 CONTROL GP-TIMING | 1 | |
| 8T6765 | 2 PLUG-PIPE (1/4-18-THD) | 1 | |
| 1638070 | 3 HARNESS AS-WIRING (TIMING) | 1 | |
| 8S4626 | SPLICE-WIRE | 1 | |
| 5P6009 | TUBE-HEAT SHRINK (9.52-MM DIA)(0.1-M) | ||
| 3E7430 | PLUG-PIPE (3/4-14-THD) | 1 | |
| 4G2544 | CONNECTOR-PLUG | 1 | |
| 7E3062 | COVER-UNILET | 1 | |
| 7E3063 | GASKET-INLET | 1 | |
| 8T6342 | TUBE-HEAT SHRINK (3.2-MM DIA)(4-CM) | ||
| 9X3406 | RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 9X4385 | PLUG AS-CONNECTOR (6-PIN) | 1 | |
| 9X8917 | SCREW-MACHINE (4-40X9.52-MM) | 4 | |
| 9Y6993 | ADAPTER | 1 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(7-CM) | ||
| 1402046 | GASKET | 1 | |
| 1638071 | CONDUIT AS | 1 | |
| 1638072 | CONDUIT AS | 1 | |
| 7E3060 | 4 ADAPTER | 1 | |
| 7W5193 | 5 CONNECTOR | 1 | |
| 9Y7361 | 6 BOOT | 12 | |
| 9Y4167 | 7 TRANSFORMER AS (IGNITION) | 12 | |
| 4W2256 | 8 PLUG AS-SPARK | 12 | |
| 1083515 | GASKET-PLUG | 1 | |
| 1086561 | GASKET | 1 | |
| 4P8134 | 9 CLIP (LADDER) | 8 | |
| 9X6772 | 10 STRAP-CABLE | 8 | |
| 9M1974 | 11 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 2915866 | 12 HARNESS AS-WIRING (IGNITION) | 1 | |
| 3T3622 | 13 CLAMP | 12 | |
| 0S1614 | 14 BOLT (1/4-20X0.5-IN) | 4 | |
| 5P0537 | 15 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 1636151 | 17 BRACKET AS | 1 | |
| 9G2731 | 18 HOLDER AS-FUSE | 2 | |
| 2S6024 | 19 FUSE (5-AMPERE) | 2 | |
| 8T6342 | 20 TUBE-HEAT SHRINK (3.2-MM DIA)(8-CM) | ||
| 1C0569 | 21 BOLT (5/16-18X0.5-IN) | 8 | |
| 5P6025 | 22 LOCKWIRE (1.2-M) | ||
| 8S8158 | 23 SEAL-WIRE | 12 | |
| 1166806 | 24 SENSOR GP-SPEED (TIMING) | 1 | |
| 3E6488 | 25 PLUG AS-CONNECTOR | 1 | |
| 5P6025 | 26 LOCKWIRE (0.1-M) | ||
| 8S8158 | 27 SEAL-WIRE | 1 | |
| 4B8407 | 28 GASKET-COPPER | 1 | |
| 5P6025 | 29 LOCKWIRE (0.3-M) | ||
| 8S8158 | 30 SEAL-WIRE | 3 | |
| 2915865 | 31 HARNESS AS-WIRING (IGNITION) | 1 | |
| 2907081 | 32 HARNESS AS-WIRING (IGNITION) | 1 | |
| 6D5234 | PLUG AS-CONNECTOR (14-PIN) | ||
| 1428607 | PLUG AS-CONNECTOR (19-PIN) | 1 |
