211-1629 IGNITION GP-GAS ENGINES/N 7DB1-UP

Group No: 211-1629

Part Number	Part Name	Qty
0T0102	1 BOLT (3/8-16X0.625-IN)	1
9X8486	2 SCREW-MACHINE (8-32X0.75-IN)	4
4B4863	3 WASHER (4.7X11X1.2-MM THK)	8
4B2043	4 NUT (8-32-THD)	4
2N2839	5 PLUG AS-SPARK	12
1083515	GASKET-PLUG	1
1059055	6 BRACKET	4
5P4116	7 WASHER-HARD (8.8X20.5X2-MM THK)	31
1C0569	8 BOLT (5/16-18X0.5-IN)	24
8L5449	9 SPACER (0.375X0.75X0.69-IN THK)	12
2W3747	10 TRANSFORMER AS	12
7E0079	11 SEAL	12
8T6765	12 PLUG-PIPE (1/4-18-THD)	1
1636108	13 CONTROL GP-TIMING	1
5M2894	14 WASHER-HARD (10.2X18.5X2.5-MM THK)	1
4P7581	15 CLIP (LADDER)	15
9X6772	16 STRAP-CABLE	25
1A9579	17 BOLT (5/16-18X1.5-IN)	13
4P8134	18 CLIP (LADDER)	8
1166806	19 SENSOR GP-SPEED (TIMING)	1
2567294	20 HARNESS AS-WIRING (TIMING)	1
5P6009	TUBE-HEAT SHRINK (9.52-MM DIA)(0.01-M)
6V2722	TUBE-HEAT SHRINK (25.4-MM DIA)(0.01-M)
8T6342	TUBE-HEAT SHRINK (3.2-MM DIA)(8-CM)
9D3955	PLUG AS-CONNECTOR (3-PIN)	1
9W0852	PIN-CONNECTOR (14-GA TO 16-GA)	1
9X4385	PLUG AS-CONNECTOR (6-PIN)	1
0928226	SPLICE	2
1030213	RECEPTACLE AS-CONNECTOR (70-PIN)	1
1257875	TUBE-HEAT SHRINK (7.44-MM DIA)(6-CM)
2L8076	TERMINAL-RING (14-GA TO 16-GA, NO. 10 SCREW)	1
1863735	PIN-CONNECTOR (16-GA TO 18-GA)	2
1931003	21 HARNESS AS-ENGINE (IGNITION)	1
7T3272	RECEPTACLE-CONNECTOR (6-PIN)	1
8T8729	PIN-CONNECTOR (16-GA TO 20-GA)	6
8T8737	PLUG-SEAL	1
0928226	SPLICE	5
1257875	TUBE-HEAT SHRINK (7.44-MM DIA)(9-CM)
5P1476	TERMINAL-FORK (14-GA TO 16-GA, NO. 10 SCREW)	1
1257874	TUBE-HEAT SHRINK (5.72-MM DIA)(3-CM)
1428607	PLUG AS-CONNECTOR (19-PIN)	1
2L8076	TERMINAL-RING (14-GA TO 16-GA, NO. 10 SCREW)	1
2502149	22 WIRE AS	12
8S8158	23 SEAL-WIRE	1
5P6025	24 LOCKWIRE (.1-M)
4B8407	25 GASKET-COPPER	1
1046202	26 CLIP (LADDER)	2
1A4273	27 BOLT (5/8-18X1.25-IN)	2
1982963	28 BRACKET-MOUNTING	1
0S1616	29 BOLT (1/4-20X1-IN)	4
5P0537	30 WASHER-HARD (7.2X14.5X2-MM THK)	8
9S8750	31 NUT-FULL (1/4-20-THD)	4
2146132	32 TUBE	12
5P8068	33 SEAL-O-RING	12
