System And Components
216-4015 IGNITION GP-GAS ENGINES/N 7DB1-UP
Group No: 216-4015
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2N2839 | 1 PLUG AS-SPARK | 12 | |
| 1083515 | GASKET-PLUG | 1 | |
| 1059055 | 2 BRACKET | 4 | |
| 5P4116 | 3 WASHER-HARD (8.8X20.5X2-MM THK) | 37 | |
| 1C0569 | 4 BOLT (5/16-18X0.5-IN) | 24 | |
| 2S6024 | 5 FUSE (5-AMPERE) | 2 | |
| 8L5449 | 6 SPACER (0.375X0.75X0.69-IN THK) | 12 | |
| 2W3747 | 7 TRANSFORMER AS | 12 | |
| 7E0079 | 8 SEAL | 12 | |
| 0T0065 | 10 BOLT (3/8-16X3.5-IN) | 1 | |
| 5M2894 | 11 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 4P7581 | 12 CLIP (LADDER) | 12 | |
| 9X6772 | 13 STRAP-CABLE | 13 | |
| 1A9579 | 14 BOLT (5/16-18X1.5-IN) | 13 | |
| 4P8134 | 15 CLIP (LADDER) | 1 | |
| 9G9150 | 16 CLIP | 1 | |
| 0S0509 | 17 BOLT (3/8-16X0.75-IN) | 1 | |
| 1166806 | 18 SENSOR GP-SPEED (TIMING) | 1 | |
| 1636108 | 19 CONTROL GP-TIMING | 1 | |
| 1636110 | 20 HARNESS AS-SENSOR (TIMING) | 1 | |
| 1636109 | 21 HARNESS AS-ENGINE (IGNITION) | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N9738 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 9G3695 | PLUG-SEAL | 1 | |
| 1428607 | PLUG AS-CONNECTOR (19-PIN) | 1 | |
| 8S8158 | 22 SEAL-WIRE | 1 | |
| 5P6025 | 23 LOCKWIRE (.1M) | 1 | |
| 9G2731 | 24 HOLDER AS-FUSE | 2 | |
| 8T6342 | 25 TUBE-HEAT SHRINK (3.2-MM DIA) | 8 | |
| 4B8407 | 26 GASKET-COPPER | 1 | |
| 2502149 | 27 WIRE AS | 12 | |
| 2146132 | 28 TUBE | 12 | |
| 5P8068 | 29 SEAL-O-RING | 12 |
