System And Components
216-4017 IGNITION GP-GAS ENGINES/N 7DB1-UP
Group No: 216-4017
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2N2839 | 1 PLUG AS-SPARK | 12 | |
| 1083515 | GASKET-PLUG | 1 | |
| 1059055 | 2 BRACKET | 4 | |
| 5P4116 | 3 WASHER-HARD (8.8X20.5X2-MM THK) | 31 | |
| 1C0569 | 4 BOLT (5/16-18X0.5-IN) | 24 | |
| 7W9825 | 5 HARNESS AS-ENGINE (IGNITION) | 1 | |
| 6V1196 | 6 SEAL-O-RING | 1 | |
| 8L5449 | 7 SPACER (0.375X0.75X0.69-IN THK) | 12 | |
| 4P8903 | 8 MAGNETO GP | 1 | |
| 2W3747 | 9 TRANSFORMER AS | 12 | |
| 2502149 | 10 WIRE AS | 12 | |
| 7E0080 | BOOT | 1 | |
| 2236350 | BOOT | 1 | |
| 7E0079 | 11 SEAL | 12 | |
| 8T6765 | 12 PLUG-PIPE (1/4-18-THD) | 1 | |
| 0T0065 | 13 BOLT (3/8-16X3.5-IN) | 1 | |
| 5M2894 | 14 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 1A2029 | 15 BOLT (3/8-16X1.125-IN) | 2 | |
| 5P6627 | 16 LOCKWIRE (0.1-M) | ||
| 4P7581 | 17 CLIP (LADDER) | 12 | |
| 9X6772 | 18 STRAP-CABLE | 13 | |
| 1A9579 | 19 BOLT (5/16-18X1.5-IN) | 13 | |
| 9X6458 | 20 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 4P8134 | 21 CLIP (LADDER) | 1 | |
| 9G9150 | 22 CLIP | 1 | |
| 0S0509 | 23 BOLT (3/8-16X0.75-IN) | 1 | |
| 2146132 | 24 TUBE | 12 | |
| 5P8068 | 25 SEAL-O-RING | 12 |
