System And Components
272-2377 IGNITION GP-GAS ENGINES/N 7DB1-UP
Group No: 272-2377
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3T3622 | 1 CLAMP | 12 | |
| 4B8407 | 2 GASKET-COPPER | 1 | |
| 4D1326 | 3 LOCKWASHER | 2 | |
| 4W2256 | 4 PLUG AS-SPARK | 12 | |
| 1083515 | GASKET-PLUG | 1 | |
| 1767748 | GASKET | 1 | |
| 6B0933 | 5 SPACER (10.31X19.05X6.35-MM THK) | 8 | |
| 8T6342 | 7 TUBE-HEAT SHRINK (3.2-MM DIA) | 8 | |
| 9X6772 | 8 STRAP-CABLE | 2 | |
| 9Y7361 | 9 BOOT | 12 | |
| 1166806 | 10 SENSOR GP-SPEED (TIMING) | 1 | |
| 2146132 | 11 TUBE | 12 | |
| 2152434 | 12 TRANSFORMER AS | 12 | |
| 2907081 | 13 HARNESS AS-WIRING | 1 | |
| 1428607 | PLUG AS-CONNECTOR (19-PIN) | 1 | |
| 2915865 | 14 HARNESS AS-WIRING | 1 | |
| 2915866 | 15 HARNESS AS-WIRING | 1 | |
| 0S1594 | 16 BOLT (3/8-16X1-IN) | 1 | |
| 0T0065 | 17 BOLT (3/8-16X3.5-IN) | 2 | |
| 2B2695 | 18 BOLT (5/16-18X0.875-IN) | 8 | |
| 4P8134 | 19 CLIP (LADDER)(LADDER) | 2 | |
| 5M2894 | 20 WASHER-HARD (10.2X18.5X2.5-MM THK) | 3 | |
| 5P4116 | 21 WASHER-HARD (8.8X20.5X2-MM THK) | 8 | |
| 5P8068 | 22 SEAL-O-RING | 12 | |
| 8T6765 | 23 PLUG-PIPE (1/4-18-THD) | 1 | |
| 1636108 | 24 CONTROL GP-TIMING | 1 | |
| 1638070 | 25 HARNESS AS-WIRING (TIMING) | 1 | |
| 3E7430 | PLUG-PIPE (3/4-14-THD) | 1 | |
| 4G2544 | CONNECTOR-PLUG | 1 | |
| 5P6009 | TUBE-HEAT SHRINK (9.52-MM DIA) | 1 | |
| 7E3062 | COVER-UNILET | 1 | |
| 7E3063 | GASKET-INLET | 1 | |
| 8T6342 | TUBE-HEAT SHRINK (3.2-MM DIA) | 4 | |
| 9X3406 | RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 9X4385 | PLUG AS-CONNECTOR (6-PIN) | 1 | |
| 9X8917 | SCREW-MACHINE (4-40X9.52-MM) | 4 | |
| 9Y6993 | ADAPTER | 1 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA) | 7 | |
| 1402046 | GASKET | 1 | |
| 1638071 | CONDUIT AS | 1 | |
| 1638072 | CONDUIT AS | 1 | |
| 3E6488 | 26 PLUG AS-CONNECTOR | 1 | |
| 2S6024 | 27 FUSE (5-AMPERE) | 2 | |
| 9G2731 | 28 HOLDER AS-FUSE | 2 |
