System And Components
7C-0481 IGNITION GP-GAS ENGINES/N 4KC147-653
Group No: 7C-0481
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1B7182 | 1 BOLT (5/16-18X1.25-IN) | 36 | |
| 9M1974 | 2 WASHER-HARD (8.8X16X2-MM THK) | 56 | |
| 1A2029 | 3 BOLT (3/8-16X1.125-IN) | 13 | |
| 5M2894 | 4 WASHER-HARD (10.2X18.5X2.5-MM THK) | 20 | |
| 9S8752 | 5 NUT-FULL (3/8-16-THD) | 10 | |
| 2B2695 | 6 BOLT (5/16-18X0.875-IN) | 20 | |
| 4S1962 | 7 CLIP (LOOP)(LARGE) | 5 | |
| 7W2171 | 8 MAGNETO GP | 1 | |
| 6V1196 | SEAL-O-RING | 1 | |
| 3S8664 | 9 CLIP (SMALL) | 5 | |
| 9Y5885 | 10 PLUG AS | 1 | |
| 7C0486 | 11 HARNESS AS-ENGINE | 1 | |
| 7N5667 | 12 BRACKET | 10 | |
| 8M2769 | 13 CLIP | 2 | |
| 9M6527 | 14 WASHER-HARD (10.2X25.5X5-MM THK) | 3 | |
| 7W6892 | 15 ROD-SUPPORT | 2 | |
| 7W4377 | 16 TRANSFORMER | 12 | |
| 4W1661 | 17 TUBE | 12 | |
| 0T0320 | 18 BOLT (7/16-14X1.25-IN) | 12 | |
| 5P8244 | WASHER-HARD (12X22.5X2.5-MM THK) | 12 | |
| 7C3294 | 19 RETAINER | 12 | |
| 1234710 | 20 EXTENSION AS | 12 | |
| 1251372 | SEAL-O-RING | 1 | |
| 1462588 | 21 SPARK PLUG | 12 | |
| 9Y6792 | GASKET-SPARK PLUG | 1 | |
| 5P8068 | 22 SEAL-O-RING | 12 | |
| 3P0650 | 23 SEAL-O-RING | 12 | |
| 7W5215 | 24 GASKET | 12 | |
| 5P8245 | 25 WASHER-HARD (13.5X25.5X3-MM THK) | 5 | |
| 0S1620 | 26 BOLT (1/2-13X0.75-IN) | 2 | |
| 7B3235 | 27 BOLT (1/2-13X1.375-IN) | 3 | |
| 8M2769 | 28 CLIP | 3 | |
| 8M2773 | 29 CLIP (LOOP) | 1 | |
| 5M2894 | 30 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 9L9132 | 31 WASHER-HARD (10.2X25.5X2.5-MM THK) | 1 | |
| 6B0933 | 32 SPACER (10.31X19.05X6.35-MM THK) | 1 | |
| 0L1143 | 33 BOLT (3/8-16X2.5-IN) | 1 |
