System And Components
7C-1144 IGNITION GP-GAS ENGINEGAS ENGINE-SPEED SENSITIVE TIMING, PROVIDES VARIABLE TIMING
Group No: 7C-1144
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1B7182 | 1 BOLT (5/16-18X1.25-IN) | 36 | |
| 9M1974 | 2 WASHER-HARD (8.8X16X2-MM THK) | 56 | |
| 1A2029 | 3 BOLT (3/8-16X1.125-IN) | 10 | |
| 5M2894 | 4 WASHER-HARD (10.2X18.5X2.5-MM THK) | 29 | |
| 1D4717 | 5 NUT (3/8-16-THD) | 10 | |
| 2B2695 | 6 BOLT (5/16-18X0.875-IN) | 20 | |
| 4S1962 | 7 CLIP (LOOP) | 5 | |
| 7W2171 | 8 MAGNETO GP | 1 | |
| 6V1196 | SEAL-O-RING | 1 | |
| 0S1594 | BOLT (3/8-16X1-IN) | 3 | |
| 3S8664 | 9 CLIP | 5 | |
| 5P4295 | 10 CLIP | 2 | |
| 7C0486 | 11 HARNESS AS-ENGINE | 1 | |
| 7N5667 | 12 BRACKET | 10 | |
| 5P9297 | 13 CLIP (LOOP) | 2 | |
| 0S0509 | 14 BOLT (3/8-16X0.75-IN) | 1 | |
| 0L1351 | 15 BOLT (3/8-16X0.875-IN) | 1 | |
| 7W2265 | 16 BOX AS-VARIABLE | 1 | |
| 7W2264 | HARNESS AS | 1 | |
| 2B0941 | 17 SPACER (10.5X19X19-MM THK) | 4 | |
| 7C1526 | 18 PLATE | 1 | |
| 3N1968 | 19 MOUNT-FLEXIBLE | 4 | |
| 1B4330 | 20 NUT (1/4-20-THD) | 8 | |
| 0S1590 | 21 BOLT (3/8-16X2-IN) | 4 | |
| 5P6025 | 22 LOCKWIRE | ||
| 7W4377 | 23 TRANSFORMER | 12 | |
| 4W1661 | 24 TUBE | 12 | |
| 0T0320 | 25 BOLT (7/16-14X1.25-IN) | 12 | |
| 5P8244 | WASHER-HARD (12X22.5X2.5-MM THK) | 12 | |
| 7C3294 | 26 RETAINER | 12 | |
| 9Y7042 | 27 EXTENSION AS | 12 | |
| 9Y2602 | 28 SPARK PLUG | 12 | |
| 5P8068 | 29 SEAL-O-RING | 12 | |
| 3P0650 | 30 SEAL-O-RING | 12 | |
| 7W5215 | 31 GASKET | 12 | |
| 5P8245 | 32 WASHER-HARD (13.5X25.5X3-MM THK) | 5 | |
| 0S1620 | 33 BOLT (1/2-13X0.75-IN) | 2 | |
| 7B3235 | 34 BOLT (1/2-13X1.375-IN) | 3 | |
| 8M2769 | 35 CLIP | 2 | |
| 7W6892 | 36 ROD-SUPPORT | 2 | |
| 5P4295 | 37 CLIP | 1 |
