System And Components
9Y-0150 IGNITION GP-GAS ENGINEAN ATTACHMENT
Group No: 9Y-0150
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9Y0152 | 1 BRACKET | 10 | |
| 2B2695 | 2 BOLT (5/16-18X0.875-IN) | 20 | |
| 9M1974 | 3 WASHER-HARD (8.8X16X2-MM THK) | 56 | |
| 9Y0153 | 4 HARNESS AS-WIRING | 1 | |
| 4F4879 | 5 BOLT (3/8-16X0.5-IN) | 1 | |
| 5M2894 | 6 WASHER-HARD (10.2X18.5X2.5-MM THK) | 15 | |
| 2D7134 | 7 STRAP AS | 1 | |
| 4P8400 | 8 BOX AS-CONTROL | 1 | |
| 7W2264 | HARNESS AS | 1 | |
| 0S0509 | 9 BOLT (3/8-16X0.75-IN) | 1 | |
| 5P9297 | 10 CLIP (LOOP) | 1 | |
| 6V1196 | 11 SEAL-O-RING | 1 | |
| 0S1594 | 12 BOLT (3/8-16X1-IN) | 3 | |
| 7W2172 | 13 MAGNETO GP | 1 | |
| 7E0875 | 14 BRACKET | 1 | |
| 0L1351 | 15 BOLT (3/8-16X0.875-IN) | 2 | |
| 7E0874 | 16 PLATE | 1 | |
| 0S1588 | 17 BOLT (3/8-16X1.25-IN) | 2 | |
| 7E3222 | 18 MOUNT-FLEXIBLE | 4 | |
| 9S8750 | 19 NUT-FULL (1/4-20-THD) | 48 | |
| 5P0537 | 20 WASHER-HARD (7.2X14.5X2-MM THK) | 48 | |
| 1B7182 | 21 BOLT (5/16-18X1.25-IN) | 36 | |
| 8T3389 | 22 U-BOLT | 20 | |
| 6I4452 | 23 TRANSFORMER AS | 16 | |
| 6V2410 | 24 SCREW-WASHER HEAD | 12 | |
| 3P0650 | 25 SEAL-O-RING | 12 | |
| 4P3415 | 26 TUBE AS | 12 | |
| 5P8068 | 27 SEAL-O-RING | 12 | |
| 9Y7042 | 28 EXTENSION AS | 12 | |
| 9Y2602 | 29 SPARK PLUG | 12 | |
| 3L6836 | 30 SPACER (0.5X0.75X0.56-IN THK) | 12 | |
| 0T0768 | 31 BOLT (7/16-14X1.75-IN) | 12 | |
| 7C3294 | 32 RETAINER | 12 | |
| 0T0055 | 33 BOLT (3/8-16X4.25-IN) | 2 | |
| 1W8129 | 34 SUPPORT | 1 | |
| 5P6025 | 35 LOCKWIRE (2.0M) | ||
| 1S1015 | 36 CLIP (LOOP) | 5 | |
| 5P8245 | 37 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 7B3235 | 38 BOLT (1/2-13X1.375-IN) | 3 | |
| 9S8752 | 39 NUT-FULL (3/8-16-THD) | 4 | |
| 7C0726 | 40 FILM | 12 |
