System And Components
195-6244 BOX GP-CONTROL PANELS/N 4KC654-UP
Group No: 195-6244
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 8 | |
| 2W6090 | 2 PLATE-IDENTIFICATION (EMERGENCY STOP) | 1 | |
| 3E0105 | 3 MOUNT | 4 | |
| 6I1418 | 4 SPACER (8.2X12.7X28.7-MM THK) | 4 | |
| 7R3029 | 5 CAP-DUST | 1 | |
| 7K1181 | 6 STRAP-CABLE | 3 | |
| 8T9655 | 7 MOUNT-ISOLATION | 8 | |
| 1735413 | 8 CLAMP | 2 | |
| 1057543 | 9 BLOCK-FUSE | 2 | |
| 1059161 | 10 CAP-DUST | 1 | |
| 1096507 | 11 SWITCH AS-PUSH BUTTON (EMERGENCY STOP) | 1 | |
| 3981723 | NUT (3/16X18-THD) | 1 | |
| 1103890 | 12 TERMINAL | 2 | |
| 1103891 | 13 COVER-END | 1 | |
| 1111324 | 14 BLOCK-CONTACT (1-POLE) | 1 | |
| 1143364 | 15 WASHER-SPECIAL (SEALING) | 4 | |
| 1243176 | 16 COVER | 1 | |
| 1312639 | 17 WASHER (3.2X9X0.5-MM THK) | 1 | |
| 1314888 | 18 GASKET | 1 | |
| 1328487 | 19 NUT-RING | 1 | |
| 1543254 | 20 GASKET | 1 | |
| 1569336 | 21 NUT-RING | 1 | |
| 1787879 | 22 SEAL-WASHER | 8 | |
| 3527965 | 23 PLUG-SEAL | 1 | |
| 1976949 | 24 STRIP-CONTACT | 1 | |
| 2075403 | 25 BAR-MOUNTING | 1 | |
| 2103936 | 26 BAR-MOUNTING | 1 | |
| 2109470 | 27 CONTROL GP-ENGINE ELECTRONIC | 1 | |
| 2212498 | 28 WIRE AS (8-GA, BLACK) | 1 | |
| 2338091 | 29 FUSE (6-AMPERE) | 1 | |
| 2345925 | 30 GASKET | 2 | |
| 2354861 | 31 TERMINAL-GROUND | 1 | |
| 2354864 | 32 FILM-IDENTIFICATION (TERMINAL STRIP) | 1 | |
| 3441076 | 33 HARNESS AS-BOX | 1 | |
| 3445585 | 34 BOX GP-JUNCTION | 1 | |
| 0365774 | 35 FUSE (15-AMPERE) | 1 | |
| 5P0537 | 36 WASHER-HARD (7.2X14.5X2-MM THK) | 7 | |
| 5P4115 | 37 WASHER-HARD (7.2X19X2-MM THK) | 4 | |
| 6V5683 | 38 BOLT (M6X1X16-MM) | 8 | |
| 8C8560 | 39 SCREW-LOCK (4-40X0.5-IN) | 4 | |
| 9S8750 | 40 NUT-FULL (1/4-20-THD) | 7 | |
| 9X6258 | 41 SCREW-MACHINE (6-32X0.5-IN) | 4 |
