Assembly
100%

2W-1442 MANIFOLD GP-EXHAUSTS/N 3RC1-195

Group No: 2W-1442
Part NumberPart NameQty
4W25071 MANIFOLD AS (LH)1
3B05512 PLUG-PIPE3
4W25063 MANIFOLD AS (RH)1
2W45854 GASKET2
2W45835 TUBE AS-BYPASS2
1D47066 BOLT (3/8-16X6-IN)32
5M2894WASHER-HARD (10.2X18.5X2.5-MM THK)32
0S15947 BOLT (3/8-16X1-IN)8
2W45788 ELBOW AS-EXHAUST1
4F5695PLUG-CUP6
3H58419 BOLT (3/8-16X1-IN)4
5M289410 WASHER-HARD (10.2X18.5X2.5-MM THK)44
3H662311 BOLT (3/8-16X2.25-IN)8
7N860612 GASKET-EXHAUST MANIFOLD16
0L207013 BOLT (3/8-16X2.25-IN)32
6L736314 STUD-TAPERLOCK4
2W457915 GASKET1
1B535516 NUT-FULL (3/8-16-THD)4
4J438217 PLUG-PIPE (1/2-14-THD)2
2W458518 GASKET2
6H171719 BOLT (1/2-13X1.125-IN)2
5P824520 WASHER-HARD (13.5X25.5X3-MM THK)2
4W305321 BRACKET1
9S875222 NUT-FULL (3/8-16-THD)2
6L856223 STUD-TAPERLOCK (3/8-16X1.77-IN)8
5B789024 PLUG-PIPE4
0S159125 BOLT (3/8-16X1.5-IN)2
9L913226 WASHER-HARD (10.2X25.5X2.5-MM THK)4
