System And Components
4P-7316 CONTROL GP-CARBURETORS/N 3RC1066-1076
Group No: 4P-7316
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4B3388 | 1 BOLT (5/16-18X1.125-IN) | 5 | |
| 9M1974 | 2 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 4F2294 | 3 NUT-JAM (5/16-24-THD)(PLATED) | 3 | |
| 1195093 | 4 ROD | 1 | |
| 7W0200 | 5 SHAFT | 1 | |
| 5L3291 | 6 BEARING AS-BALL | 2 | |
| 3B1915 | 7 BOLT (3/8-16X1.375-IN) | 2 | |
| 9S8752 | NUT-FULL (3/8-16-THD) | 2 | |
| 2W5404 | 8 LEVER | 1 | |
| 1B8701 | KEY-WOODRUFF | 2 | |
| 2W5405 | 9 ROD | 1 | |
| 4W4945 | 10 LEVER AS | 1 | |
| 4W4944 | LEVER-GOVERNOR | 1 | |
| 4W4946 | 11 COVER AS | 1 | |
| 6B2730 | 12 BEARING AS | 1 | |
| 1149269 | 13 SLEEVE | 6 | |
| 4P0708 | 14 LEVER | 1 | |
| 5M2894 | 15 WASHER-HARD (10.2X18.5X2.5-MM THK) | 15 | |
| 1A2029 | 16 BOLT (3/8-16X1.125-IN) | 15 | |
| 8N9885 | 17 GASKET-COVER | 1 | |
| 6V9163 | 18 ROD END (BEARING)(LH THREAD) | 2 | |
| 8L4496 | 19 NUT-JAM (5/16-24 LH-THD)(NON-PLATED) | 3 | |
| 9S8751 | 20 NUT-FULL (5/16-24-THD) | 2 | |
| 8G1825 | 21 ROD | 1 | |
| 9Y2636 | 22 LEVER | 1 | |
| 7E9748 | 23 ROD END (BEARING) | 2 | |
| 1224677 | 24 ROD END (THREAD, LH) | 1 | |
| 5S0003 | 25 NUT (5/16-18-THD) | 4 | |
| 1225941 | 26 ROD END | 1 |
