System And Components
2W-1474 IGNITION GP-GAS ENGINES/N 3RC1-111
Group No: 2W-1474
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1B7182 | 1 BOLT (5/16-18X1.25-IN) | 48 | |
| 9M1974 | 2 WASHER-HARD (8.8X16X2-MM THK) | 78 | |
| 1A2029 | 3 BOLT (3/8-16X1.125-IN) | 15 | |
| 5M2894 | 4 WASHER-HARD (10.2X18.5X2.5-MM THK) | 33 | |
| 1D4717 | 5 NUT (3/8-16-THD) | 15 | |
| 2B2695 | 6 BOLT (5/16-18X0.875-IN) | 30 | |
| 4B1236 | 7 SCREW-MACHINE | 1 | |
| 4W3229 | 8 MAGNETO GP | 1 | |
| 6V1196 | SEAL-O-RING | 1 | |
| 0S1594 | BOLT (3/8-16X1-IN) | 3 | |
| 5P6627 | 9 LOCKWIRE | ||
| 8M2769 | 10 CLIP | 2 | |
| 4W0166 | 11 HARNESS AS-ENGINE | 1 | |
| 7W7779 | ROD-SUPPORT | 2 | |
| 7N5667 | 12 BRACKET | 15 | |
| 3S8664 | 13 CLIP | 7 | |
| 4S1962 | 14 CLIP (LOOP) | 7 | |
| 4S4455 | 15 CLIP | 1 | |
| 5P6627 | 16 LOCKWIRE | ||
| 7W3863 | 17 TRANSFORMER AS | 16 | |
| 4W1661 | 18 TUBE | 16 | |
| 0T0320 | 19 BOLT (7/16-14X1.25-IN) | 16 | |
| 5P8244 | WASHER-HARD (12X22.5X2.5-MM THK) | 16 | |
| 7C3294 | 20 RETAINER | 16 | |
| 7W1453 | 21 EXTENSION AS | 16 | |
| 7W2257 | 22 SPARK PLUG | 16 | |
| 5P8068 | 23 SEAL-O-RING | 16 | |
| 3P0650 | 24 SEAL-O-RING | 16 | |
| 7W5215 | 25 GASKET | 16 | |
| 5P8245 | 26 WASHER-HARD (13.5X25.5X3-MM THK) | 5 | |
| 0S1620 | 27 BOLT (1/2-13X0.75-IN) | 3 | |
| 7B3235 | 28 BOLT (1/2-13X1.375-IN) | 2 | |
| 8M2769 | 29 CLIP | 2 | |
| 8D9947 | 30 CLIP | 1 |
