System And Components
2W-1474 IGNITION GP-GAS ENGINES/N 3RC112-UP
Group No: 2W-1474
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4W0166 | 1 HARNESS AS-ENGINE | 1 | |
| 3S8664 | 2 CLIP | 6 | |
| 8D9947 | 3 CLIP | 1 | |
| 4S1962 | 4 CLIP (LOOP) | 7 | |
| 7W2257 | 5 SPARK PLUG | 16 | |
| 7N5667 | 6 BRACKET | 14 | |
| 6V1196 | 7 SEAL-O-RING | 1 | |
| 0S1594 | 8 BOLT (3/8-16X1-IN) | 3 | |
| 5M2894 | 9 WASHER-HARD (10.2X18.5X2.5-MM THK) | 31 | |
| 4W3229 | 10 MAGNETO GP | 1 | |
| 0S1620 | 11 BOLT (1/2-13X0.75-IN) | 3 | |
| 5P8245 | 12 WASHER-HARD (13.5X25.5X3-MM THK) | 5 | |
| 7B3235 | 13 BOLT (1/2-13X1.375-IN) | 2 | |
| 8M2769 | 14 CLIP | 4 | |
| 5P8068 | 15 SEAL-O-RING | 16 | |
| 1A2029 | 16 BOLT (3/8-16X1.125-IN) | 14 | |
| 1D4717 | 17 NUT (3/8-16-THD) | 14 | |
| 2B2695 | 18 BOLT (5/16-18X0.875-IN) | 28 | |
| 9M1974 | 19 WASHER-HARD (8.8X16X2-MM THK) | 76 | |
| 1B7182 | 20 BOLT (5/16-18X1.25-IN) | 48 | |
| 7W3863 | 21 TRANSFORMER AS | 16 | |
| 5P6025 | 22 LOCKWIRE | ||
| 7W5215 | 23 GASKET | 16 | |
| 3P0650 | 24 SEAL-O-RING | 16 | |
| 4W1661 | 25 TUBE | 16 | |
| 0T0320 | 26 BOLT (7/16-14X1.25-IN) | 16 | |
| 5P8244 | 27 WASHER-HARD (12X22.5X2.5-MM THK) | 16 | |
| 7C3294 | 28 RETAINER | 16 | |
| 7W1453 | 29 EXTENSION AS | 16 | |
| 4B1236 | 30 SCREW-MACHINE | 1 | |
| 4S4455 | 31 CLIP | 1 | |
| 7W7779 | 32 ROD-SUPPORT | 2 |
