System And Components
4P-2057 IGNITION GP-GAS ENGINEAN ATTACHMENT
Group No: 4P-2057
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0S1594 | 1 BOLT (3/8-16X1-IN) | 4 | |
| 0T0055 | 2 BOLT (3/8-16X4.25-IN) | 2 | |
| 0T0768 | 3 BOLT (7/16-14X1.75-IN) | 16 | |
| 1B7182 | 4 BOLT (5/16-18X1.25-IN) | 48 | |
| 1S1015 | 5 CLIP (LOOP) | 4 | |
| 1W8129 | 6 SUPPORT | 1 | |
| 2B2695 | 7 BOLT (5/16-18X0.875-IN) | 24 | |
| 3L6836 | 8 SPACER (0.5X0.75X0.56-IN THK) | 16 | |
| 3P0650 | 9 SEAL-O-RING | 16 | |
| 4P3415 | 10 TUBE AS | 16 | |
| 4P7581 | 11 CLIP (LADDER) | 1 | |
| 5M2894 | 12 WASHER-HARD (10.2X18.5X2.5-MM THK) | 5 | |
| 5P0537 | 13 WASHER-HARD (7.2X14.5X2-MM THK) | 24 | |
| 5P6025 | 14 LOCKWIRE | ||
| 5P8068 | 15 SEAL-O-RING | 16 | |
| 5P8245 | 16 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6I4452 | 17 TRANSFORMER AS | 16 | |
| 7W4377 | TRANSFORMER | 1 | |
| 1462589 | 18 SPARK PLUG | 16 | |
| 6V1196 | 19 SEAL-O-RING | 1 | |
| 6V2410 | 20 SCREW-WASHER HEAD | 16 | |
| 7B3235 | 21 BOLT (1/2-13X1.375-IN) | 2 | |
| 7C3294 | 22 RETAINER | 16 | |
| 7W2172 | 23 MAGNETO GP | 1 | |
| 8T3389 | 24 U-BOLT | 12 | |
| 9M1974 | 25 WASHER-HARD (8.8X16X2-MM THK) | 72 | |
| 9M6527 | 26 WASHER-HARD (10.2X25.5X5-MM THK) | 3 | |
| 9S8750 | 27 NUT-FULL (1/4-20-THD) | 24 | |
| 9S8752 | 28 NUT-FULL (3/8-16-THD) | 2 | |
| 9X6772 | 29 STRAP-CABLE | 1 | |
| 9Y0152 | 30 BRACKET | 12 | |
| 9Y0154 | 31 HARNESS AS-WIRING | 1 | |
| 9Y5885 | 32 PLUG AS | 1 | |
| 1234710 | 33 EXTENSION AS | 16 | |
| 1251372 | SEAL-O-RING | 1 |
