7C-0482 IGNITION GP-GAS ENGINEFIXED TIMING

Group No: 7C-0482
Part NumberPart NameQty
1B71821 BOLT (5/16-18X1.25-IN)48
9M19742 WASHER-HARD (8.8X16X2-MM THK)78
1A20293 BOLT (3/8-16X1.125-IN)15
5M28944 WASHER-HARD (10.2X18.5X2.5-MM THK)33
1D47175 NUT (3/8-16-THD)15
2B26956 BOLT (5/16-18X0.875-IN)30
4S19627 CLIP (LOOP)7
7W17898 MAGNETO GP1
6V1196SEAL-O-RING1
0S1594BOLT (3/8-16X1-IN)3
3S86649 CLIP7
8M276910 CLIP2
7C048711 HARNESS AS-ENGINE1
7N566712 BRACKET15
4S445513 CLIP1
5P567714 WIRE (18-GA, BLACK)
7W437715 TRANSFORMER16
4W166116 TUBE16
0T032017 BOLT (7/16-14X1.25-IN)16
5P8244WASHER-HARD (12X22.5X2.5-MM THK)16
7C329418 RETAINER16
7W145319 EXTENSION AS16
7W225720 SPARK PLUG16
5P806821 SEAL-O-RING16
3P065022 SEAL-O-RING16
7W521523 GASKET16
5P824524 WASHER-HARD (13.5X25.5X3-MM THK)5
0S162025 BOLT (1/2-13X0.75-IN)3
7B323526 BOLT (1/2-13X1.375-IN)2
8D994727 CLIP1
8M276928 CLIP2
7W777929 ROD-SUPPORT2
