System And Components
7C-1145 IGNITION GP-GAS ENGINEGAS ENGINE - SPEED SENSITIVE TIMING - PROVIDES VARIABLE TIMING
Group No: 7C-1145
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1B7182 | 1 BOLT (5/16-18X1.25-IN) | 48 | |
| 9M1974 | 2 WASHER-HARD (8.8X16X2-MM THK) | 76 | |
| 1A2029 | 3 BOLT (3/8-16X1.125-IN) | 14 | |
| 5M2894 | 4 WASHER-HARD (10.2X18.5X2.5-MM THK) | 37 | |
| 1D4717 | 5 NUT (3/8-16-THD) | 14 | |
| 2B2695 | 6 BOLT (5/16-18X0.875-IN) | 28 | |
| 4S1962 | 7 CLIP (LOOP) | 7 | |
| 7W2172 | 8 MAGNETO GP | 1 | |
| 6V1196 | SEAL-O-RING | 1 | |
| 0S1594 | BOLT (3/8-16X1-IN) | 3 | |
| 3S8664 | 9 CLIP | 6 | |
| 8M2769 | 10 CLIP | 2 | |
| 7C0487 | 11 HARNESS AS-ENGINE | 1 | |
| 7N5667 | 12 BRACKET | 14 | |
| 5P9297 | 13 CLIP (LOOP) | 2 | |
| 0S0509 | 14 BOLT (3/8-16X0.75-IN) | 1 | |
| 0L1351 | 15 BOLT (3/8-16X0.875-IN) | 1 | |
| 7W2266 | 16 BOX AS-VARIABLE | 1 | |
| 7W2264 | HARNESS AS | 1 | |
| 2B0941 | 17 SPACER (10.5X19X19-MM THK) | 4 | |
| 7C1526 | 18 PLATE | 1 | |
| 7E3222 | 19 MOUNT-FLEXIBLE | 4 | |
| 1B4330 | 20 NUT (1/4-20-THD) | 8 | |
| 0S1590 | 21 BOLT (3/8-16X2-IN) | 4 | |
| 4S4455 | 22 CLIP | 1 | |
| 5P6025 | 23 LOCKWIRE | ||
| 7W4377 | 24 TRANSFORMER | 16 | |
| 4W1661 | 25 TUBE | 16 | |
| 0T0320 | 26 BOLT (7/16-14X1.25-IN) | 16 | |
| 5P8244 | WASHER-HARD (12X22.5X2.5-MM THK) | 16 | |
| 7C3294 | 27 RETAINER | 16 | |
| 9Y7042 | 28 EXTENSION AS | 16 | |
| 4P8294 | 29 SPARK PLUG | 16 | |
| 5P8068 | 30 SEAL-O-RING | 16 | |
| 3P0650 | 31 SEAL-O-RING | 16 | |
| 7W5215 | 32 GASKET | 16 | |
| 5P8245 | 33 WASHER-HARD (13.5X25.5X3-MM THK) | 5 | |
| 0S1620 | 34 BOLT (1/2-13X0.75-IN) | 3 | |
| 7B3235 | 35 BOLT (1/2-13X1.375-IN) | 2 | |
| 8M2769 | 36 CLIP | 2 | |
| 7W7779 | 37 ROD-SUPPORT | 2 | |
| 8D9947 | 38 CLIP | 1 |
