Assembly
100%

9Y-5311 IGNITION GP-GAS ENGINES/N 3RC146-UP

Group No: 9Y-5311
Part NumberPart NameQty
0L11431 BOLT (3/8-16X2.5-IN)1
0L13512 BOLT (3/8-16X0.875-IN)2
0S15884 BOLT (3/8-16X1.25-IN)2
0S16205 BOLT (1/2-13X0.75-IN)3
0T03206 BOLT (7/16-14X1.25-IN)16
1A20297 BOLT (3/8-16X1.125-IN)17
1B71828 BOLT (5/16-18X1.25-IN)48
2B26959 BOLT (5/16-18X0.875-IN)28
2D713410 STRAP AS1
3P065011 SEAL-O-RING16
3S866412 CLIP6
4F487913 BOLT (3/8-16X0.5-IN)1
4S196214 CLIP (LOOP)7
4S445515 CLIP1
4W166116 TUBE16
5M289417 WASHER-HARD (10.2X18.5X2.5-MM THK)36
5P053718 WASHER-HARD (7.2X14.5X2-MM THK)8
5P806819 SEAL-O-RING16
5P824420 WASHER-HARD (12X22.5X2.5-MM THK)16
5P824521 WASHER-HARD (13.5X25.5X3-MM THK)5
6B093323 SPACER (10.31X19.05X6.35-MM THK)1
6V119624 SEAL-O-RING1
7B323525 BOLT (1/2-13X1.375-IN)2
7C048726 HARNESS AS-ENGINE1
7C329427 RETAINER16
7E087428 PLATE1
7E087529 BRACKET1
7E322230 MOUNT-FLEXIBLE4
7N566731 BRACKET14
7W217232 MAGNETO GP1
7W437733 TRANSFORMER16
7W521534 GASKET16
7W777935 ROD-SUPPORT2
8D994736 CLIP1
8M276937 CLIP4
8M277338 CLIP (LOOP)1
9L913239 WASHER-HARD (10.2X25.5X2.5-MM THK)1
9M197440 WASHER-HARD (8.8X16X2-MM THK)76
9M652741 WASHER-HARD (10.2X25.5X5-MM THK)3
9S875042 NUT-FULL (1/4-20-THD)8
9S875243 NUT-FULL (3/8-16-THD)16
123471044 EXTENSION AS16
136367945 BOX AS-CONTROL1
7W2264HARNESS AS1
146258846 SPARK PLUG16
9X6772STRAP-CABLE5
9Y6792GASKET-SPARK PLUG16
