System And Components
7N-6107 CONTROL GP-CARBURETOR
Group No: 7N-6107
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4D3088 | 1 WASHER (0.266X0.438X0.19-IN THK) | 2 | |
| 9F7022 | 2 BOLT (1/4-20X1.5-IN) | 2 | |
| 5P0537 | 3 WASHER-HARD (7.2X14.5X2-MM THK) | 10 | |
| 2D6235 | 4 LOCKNUT (1/4-20-THD) | 6 | |
| 6L3353 | 5 ROD END | 4 | |
| 7N2982 | 6 ROD | 1 | |
| 1A8285 | 7 NUT-JAM (5/16-24-THD) | 4 | |
| 7N2983 | 8 ROD | 1 | |
| 5H1351 | 9 PIN-SPRING | 1 | |
| 7N2985 | 10 BRACKET AS-LINKAGE | 1 | |
| 7L4964 | FITTING-DRIVE | 2 | |
| 7L6910 | 11 BEARING | 2 | |
| 0S1594 | 12 BOLT (3/8-16X1-IN) | 3 | |
| 5M2894 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 3 | |
| 5S8055 | 13 GASKET | 1 | |
| 2A5546 | 14 BOLT (1/4-20X1.375-IN) | 2 | |
| 9F8249 | 15 LEVER-CONTROL | 2 | |
| 5H2532 | 16 KEY-WOODRUFF | 2 | |
| 5B2968 | 17 WASHER | 2 | |
| 7N2984 | 18 SHAFT-CARBURETOR CONTROL | 1 | |
| 3B4617 | 19 PIN-COTTER | 2 | |
| 7B2742 | 20 BOLT (1/4-20X1.25-IN) | 2 |
