System And Components
7N-8354 FASTENER GP-FUEL INJ PUMPAN ATTACHMENT
Group No: 7N-8354
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8N0086 | 1 TUBE AS | 1 | |
| 0308370 | 2 ADAPTER-PIPE | 1 | |
| 5K9244 | 3 ELBOW-FLARED | 1 | |
| 6K1972 | 4 ELBOW-FLARED | 1 | |
| 9L4007 | 5 ELBOW-FLARED | 1 | |
| 5P7039 | 6 CONNECTOR | 1 | |
| 8N2427 | 7 TUBE AS-OIL DRAIN | 1 | |
| 1B4202 | 8 NUT (5/16-24-THD) | 2 | |
| 1D4716 | NUT-FULL (5/16-18-THD) | 2 | |
| 9M1974 | WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 7N9203 | 9 GASKET | 1 | |
| 0L1143 | 10 BOLT (3/8-16X2.5-IN) | 2 | |
| 1B4367 | 11 BOLT (5/8-11X3-IN) | 2 | |
| 6L3528 | 12 GASKET | 1 | |
| 7N3484 | 13 TUBE AS | 1 | |
| 3J7352 | 14 CONNECTOR | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 9F7022 | 15 BOLT (1/4-20X1.5-IN) | 2 | |
| 4D3088 | 16 WASHER (0.266X0.438X0.19-IN THK)(4.8MM .19 IN THK) | 2 | |
| 2D6235 | 17 LOCKNUT (1/4-20-THD) | 6 | |
| 5P0537 | 18 WASHER-HARD (7.2X14.5X2-MM THK) | 10 | |
| 5H1351 | 19 PIN-SPRING | 1 | |
| 8N5399 | 20 ROD-CARBURETOR CONTROL | 1 | |
| 7N2985 | 21 BRACKET AS-LINKAGE | 1 | |
| 5S8055 | 22 GASKET | 1 | |
| 0S1594 | 23 BOLT (3/8-16X1-IN) | 3 | |
| 5M2894 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 3 | |
| 7L4964 | 24 FITTING-DRIVE | 2 | |
| 7N3477 | 25 ROD-CONTROL | 1 | |
| 6L3353 | 26 ROD END | 4 | |
| 5H2532 | 27 KEY-WOODRUFF | 2 | |
| 7N2984 | 28 SHAFT-CARBURETOR CONTROL | 1 | |
| 5B2968 | 29 WASHER | 2 | |
| 3B4617 | 30 PIN-COTTER | 2 | |
| 9F8249 | 31 LEVER-CONTROL | 2 | |
| 2A5546 | 32 BOLT (1/4-20X1.375-IN) | 2 | |
| 1A8285 | 33 NUT-JAM (5/16-24-THD) | 4 | |
| 7B2742 | 34 BOLT (1/4-20X1.25-IN) | 2 | |
| 7L6910 | 35 BEARING | 2 |
