System And Components
2W-6617 IGNITION GP-GAS ENGINEFOR USE WITH ALTRONIC IGNITION GP
Group No: 2W-6617
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1C0569 | 1 BOLT (5/16-18X0.5-IN) | 1 | |
| 9M1974 | 2 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 7W2479 | 3 WIRE AS-PLUG | 6 | |
| 5M2894 | 4 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 8L5850 | 5 PANEL AS-INSTRUMENT | 1 | |
| 3N2780 | 6 GAUGE-OIL PRESSURE (ENGINE) | 1 | |
| 6L2309 | 7 SWITCH-STOP | 1 | |
| 8L5849 | 8 SWITCH-MAGNETIC | 1 | |
| 3N2781 | 9 GAUGE-WATER TEMPERATURE | 1 | |
| 1S0996 | 10 CLIP | 2 | |
| 2W3747 | 11 TRANSFORMER AS | 6 | |
| 2L8076 | 12 TERMINAL-RING (14-GA TO 16-GA, NO. 10 SCREW) | 12 | |
| 6V3964 | 13 WASHER-HARD (8.8X25.5X5-MM THK) | 12 | |
| 2B2695 | 14 BOLT (5/16-18X0.875-IN) | 12 | |
| 2W3748 | 15 HARNESS AS-WIRING | 1 | |
| 8L8413 | 16 STRAP-CABLE (WHITE) | 30 | |
| 8D0693 | 17 WIRE AS | 2 | |
| 5P5624 | 18 WIRE (14-GA, BLACK) | ||
| 8M0537 | 19 TERMINAL | 1 | |
| 2W5129 | 20 WIRE AS | 1 | |
| 5P5624 | 21 WIRE (14-GA, BLACK) | ||
| 2L8076 | 22 TERMINAL-RING (14-GA TO 16-GA, NO. 10 SCREW) | 2 | |
| 5P5624 | 23 WIRE (14-GA, BLACK) | ||
| 9M9093 | 24 FERRULE | 2 | |
| 2N2839 | 25 PLUG AS-SPARK | 6 | |
| 7N2587 | 26 GEAR GP-MAGNETO DRIVE (14-TEETH) | 1 | |
| 8M8157 | 27 SEAL-O-RING | 6 | |
| 5P0695 | 28 CONDUIT | ||
| 2W3749 | 29 MAGNETO GP | 1 | |
| 6L5270 | 30 GASKET-MAGNETO | 1 | |
| 3B1915 | 31 BOLT (3/8-16X1.375-IN) | 2 | |
| 2L8066 | TERMINAL-RING (10-GA TO 12-GA, NO. 10 SCREW)(GROUND) | 4 | |
| 2H2143 | MARKER | 1 |
