System And Components
7L-3031 MAGNETO ASPART OF 7N-3973, 8N-2038 IGNITION GP-GAS ENGINE
Group No: 7L-3031
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6L3797 | 1 NUT-CAMSHAFT | 1 | |
| 8F5488 | 2 SCREW-MACHINE | 1 | |
| 6L3798 | 3 CAMSHAFT | 1 | |
| 8B9318 | KEY-WOODRUFF | 1 | |
| 6L3827 | 4 PLATE-IDENTIFICATION | 1 | |
| 2H3880 | SCREW-DRIVE (NO 2X0.125-IN) | 2 | |
| 6L3800 | 5 PLATE-SUPPORT | 1 | |
| 6L3801 | 6 RING-RETAINING | 1 | |
| 8L5878 | 7 SUPPORT & BEARING AS | 1 | |
| 6L3802 | 8 SHAFT AS | 1 | |
| 6L3805 | 9 WEDGE-COIL | 2 | |
| 6N0404 | 10 HOUSING AS | 1 | |
| 6L3807 | 11 COVER-VENT | 2 | |
| 6L3809 | SCREEN-VENT | 2 | |
| 6L3804 | 12 COIL AS | 1 | |
| 3N4137 | 13 RING-RETAINING | 1 | |
| 6F5645 | 14 BALL BEARING | 1 | |
| 9B1117 | 15 LOCKWASHER | 1 | |
| 1B8702 | 17 KEY-WOODRUFF | 1 | |
| 6L3811 | 18 NUT-COUPLING | 1 | |
| 6L3812 | WASHER | 1 | |
| 6L3829 | 19 COUPLING AS | 1 | |
| 6L3832 | SHELL-COUPLING | 1 | |
| 6L3837 | 20 SPRING-IMPULSE | 1 | |
| 6L3835 | 21 HUB AS-COUPLING | 1 | |
| 6L3823 | 22 ROTOR AS | 1 | |
| 6L3826 | 23 PIN-STOP | 1 | |
| 6N0403 | 24 SEAL-LIP TYPE | 1 | |
| 2L8509 | 25 RING-LOCK | 1 | |
| 3B4504 | 26 LOCKWASHER | 2 | |
| 9B7233 | 27 LOCKWASHER | 4 | |
| 4B1297 | 28 SCREW-MACHINE | 4 | |
| 1H3333 | 29 SCREW AS-MACHINE | 3 | |
| 7M4824 | 30 SCREW AS-MACHINE | 1 | |
| 4B1321 | 31 SCREW-MACHINE | 2 | |
| 8L8490 | 32 BOLT-SOCKET HEAD (6-32X0.312-IN) | 1 | |
| 6L3844 | 33 CONDENSER AS | 1 | |
| 5F8251 | 34 SCREW AS-MACHINE | 2 | |
| 4B4863 | WASHER (4.7X11X1.2-MM THK) | 2 | |
| 7L3126 | 35 CAP-END | 1 | |
| 6L3822 | 36 WIRE AS | 2 | |
| 6L3807 | 37 COVER-VENT | 2 | |
| 6L3809 | SCREEN-VENT | 1 | |
| 6L3839 | 38 SCREW-WINDOW | 1 | |
| 6L3822 | 39 WIRE AS | 1 | |
| 6L3842 | 40 CIRCUIT BREAKER AS | 1 | |
| 6L3843 | WICK | 1 | |
| 8L8476 | 41 DISC AS | 1 | |
| 6L3813 | 42 COVER AS-END CAP | 1 | |
| 6L3815 | COVER AS | 1 | |
| 6L3817 | 43 GROMMET | 6 | |
| 6L3821 | 44 SPACER | 4 | |
| 6L3818 | 45 BLOCK AS | 1 | |
| 6L3820 | 46 BRUSH AS | 7 | |
| 6L3717 | KIT-MAGNETO GASKET | 1 | |
| 1N9343 | KIT-MAGNETO HARDWARE | 1 | |
| 6N0710 | KIT-MAGNETO OVERHAUL | 1 | |
| 8L5783 | KIT-BEARING | 1 | |
| 8L6154 | KIT-CCW COUPLING | 1 | |
| 8L8488 | KIT-DISC | 1 |
