System And Components
300-5524 CYLINDER HEAD GPS/N 4FD3013-UP
Group No: 300-5524
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2A4429 | 1 LOCK-RETAINER | 48 | |
| 2N7174 | 2 GASKET | 6 | |
| 4N5906 | 3 SPRING-VALVE | 24 | |
| 6N7154 | 4 ROTOCOIL AS | 24 | |
| 2120932 | 5 VALVE-INLET | 12 | |
| 2120933 | 6 VALVE-EXHAUST | 12 | |
| 2120936 | 7 SEAT-VALVE (EXHAUST)(EXHAUST) | 12 | |
| 2137536 | 8 GUIDE-VALVE (INLET)(INLET) | 12 | |
| 2137537 | 9 GUIDE-VALVE (EXHAUST)(EXHAUST) | 12 | |
| 2137539 | 10 ADAPTER | 6 | |
| 2143286 | 11 SEAT-VALVE (INLET)(INLET) | 12 | |
| 2146051 | 12 SEAL | 12 | |
| 2236518 | 13 CYLINDER HEAD AS | 1 | |
| 3B0623 | 13A PLUG-CUP (25.73-MM OD) | 10 | |
| 3B0645 | 13B PLUG-CUP (32.08-MM OD) | 12 | |
| 8T6762 | 13C PLUG-PIPE (1/2-14-THD) | 4 | |
| 8T6767 | 13D PLUG-PIPE (3/8-18-THD) | 1 | |
| 1090073 | 14 SEAL-O-RING | 6 | |
| 2N5775 | 15 DOWEL | 12 |
