System And Components
7C-9716 AIR CLEANER GPS/N 4FD1-UP
Group No: 7C-9716
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1N3965 | 1 AIR CLEANER GP | 1 | |
| 4W5828 | 2 CAP-AIR CLEANER | 1 | |
| 2K4973 | 3 LOCKNUT (3/8-16-THD) | 10 | |
| 2B6296 | 4 STUD | 10 | |
| 1P9390 | 5 GASKET-OUTLET | 1 | |
| 9Y1630 | 6 FLANGE | 1 | |
| 0S1594 | 7 BOLT (3/8-16X1-IN) | 4 | |
| 7E2604 | 8 FLANGE | 1 | |
| 7E2603 | 9 HOSE | 1 | |
| 7X3338 | 10 BOLT (3/8-16X1.75-IN) | 4 | |
| 5M2894 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 7W9217 | 11 GASKET | 1 | |
| 5P0599 | 12 CLAMP-BAND | 1 | |
| 5P0600 | 13 CLAMP-HOSE | 1 | |
| 7C9739 | 14 GASKET | 1 | |
| 5L3233 | 15 FITTING-CONNECTOR | 1 | |
| 4W5820 | 16 INDICATOR-AIR FILTER CHANGE | 1 | |
| 1T0822 | 17 BOLT-12 POINT HEAD (3/8-16X0.75-IN) | 2 | |
| 7B3235 | 18 BOLT (1/2-13X1.375-IN) | 4 | |
| 5P8245 | WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 1D4719 | NUT-FULL (1/2-13-THD) | 4 |
