System And Components
113-8461 CARBURETOR GPS/N 4FD1-UP
Group No: 113-8461
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5B4685 | 1 PIN-TAPERED | 1 | |
| 8L2786 | 2 SEAL-O-RING | 1 | |
| 9M1974 | 3 WASHER-HARD (8.8X16X2-MM THK) | 18 | |
| 7W9636 | 4 CARBURETOR GP | 1 | |
| 5M2894 | 5 WASHER-HARD (10.2X18.5X2.5-MM THK) | 13 | |
| 7C9727 | 6 ELBOW | 1 | |
| 3B1915 | 7 BOLT (3/8-16X1.375-IN) | 8 | |
| 0S1588 | 8 BOLT (3/8-16X1.25-IN) | 5 | |
| 9S4185 | 9 PLUG (3/4-16-THD) | 1 | |
| 4L4642 | 10 GASKET | 1 | |
| 7C9711 | 11 GASKET | 1 | |
| 7C9728 | 12 TUBE AS-OUTLET | 1 | |
| 9Y0671 | 13 BRACE | 1 | |
| 7C8258 | 14 TUBE AS | 1 | |
| 0S1615 | 15 BOLT (1/4-20X0.75-IN) | 4 | |
| 5S0003 | 16 NUT (5/16-18-THD) | 4 | |
| 2B2695 | 17 BOLT (5/16-18X0.875-IN) | 6 | |
| 5L1150 | 18 GASKET | 2 | |
| 7W7263 | 19 ADAPTER | 1 | |
| 9S8752 | 20 NUT-FULL (3/8-16-THD) | 4 | |
| 2N8630 | 21 GASKET | 1 | |
| 7L3201 | 22 JOINT AS-TUBE | 1 | |
| 8L8585 | SEAL | 2 | |
| 7C9379 | 23 GASKET | 1 | |
| 0S1618 | 24 BOLT (5/16-18X1-IN) | 3 | |
| 1B7182 | 25 BOLT (5/16-18X1.25-IN) | 1 | |
| 8T6764 | 26 PLUG-PIPE (1/8-27-THD) | 1 | |
| 9Y0670 | 27 PLATE | 1 | |
| 7C1147 | 28 THROTTLE GP | 1 | |
| 9Y5304 | KIT-BEARING | 1 | |
| 6L5285 | 29 SHAFT-THROTTLE | 1 | |
| 6L5287 | DISC-THROTTLE | 1 | |
| 6L5296 | 30 SCREW-PIN (10-32X0.75-IN) | 1 | |
| 9Y1296 | 31 LEVER AS-THROTTLE | 1 | |
| 6L5286 | 32 LEVER AS-STOP | 1 | |
| 1B2790 | 33 BOLT (5/16-18X1.375-IN) | 4 |
