System And Components
121-7042 CARBURETOR GPS/N 4FD1-UP
Group No: 121-7042
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1217043 | 1 CARBURETOR GP | 1 | |
| 5B4685 | 2 PIN-TAPERED | 1 | |
| 9M1974 | 3 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 5M2894 | 4 WASHER-HARD (10.2X18.5X2.5-MM THK) | 16 | |
| 3B1915 | 5 BOLT (3/8-16X1.375-IN) | 8 | |
| 7W9217 | 6 GASKET | 1 | |
| 1204469 | 7 TUBE AS-OUTLET | 1 | |
| 1208408 | 8 TUBE AS-AIR | 1 | |
| 9S8752 | 9 NUT-FULL (3/8-16-THD) | 4 | |
| 1B7182 | 10 BOLT (5/16-18X1.25-IN) | 4 | |
| 5L1150 | 11 GASKET | 2 | |
| 7W7263 | 12 ADAPTER | 1 | |
| 5S0003 | 13 NUT (5/16-18-THD) | 4 | |
| 2N8630 | 14 GASKET | 1 | |
| 7L3201 | 15 JOINT AS-TUBE | 1 | |
| 8L8585 | SEAL | 2 | |
| 7C1147 | 16 THROTTLE GP | 1 | |
| 6L5285 | SHAFT-THROTTLE | 1 | |
| 6L5286 | LEVER AS-STOP | 1 | |
| 6L5287 | DISC-THROTTLE | 1 | |
| 6L5296 | SCREW-PIN (10-32X0.75-IN) | 1 | |
| 9Y1296 | LEVER AS-THROTTLE | 1 | |
| 9Y5304 | KIT-BEARING | 1 | |
| 0S1588 | 17 BOLT (3/8-16X1.25-IN) | 4 |
