System And Components
157-0961 GOVERNOR GPS/N 4FD1-UP
Group No: 157-0961
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8L8883 | 1 SHAFT | 1 | |
| 9S4671 | 2 SEAL-LIP TYPE | 1 | |
| 2N2168 | 3 SCREW-ADJUSTMENT | 1 | |
| 2P8737 | 4 HOUSING AS-GOVERNOR | 1 | |
| 9S0798 | 5 BUSHING | 1 | |
| 8S0134 | 6 BUSHING | 1 | |
| 4F4585 | 7 PLUG-CORE | 1 | |
| 8M8403 | 8 SPRING-GUIDE | 1 | |
| 2S7905 | 9 PLUG-PIPE | 2 | |
| 7D5473 | 10 BOLT-SOCKET HEAD (8-32X0.75-IN) | 1 | |
| 7N1651 | 11 COLLAR-LOAD STOP | 1 | |
| 8M8739 | 12 BOLT-LOAD STOP | 1 | |
| 8H9181 | 13 SPRING-BUMPER | 1 | |
| 6N3504 | 14 SEAT-GOVERNOR SPRING | 1 | |
| 9M3160 | 15 SPRING | 1 | |
| 1144812 | 16 RISER-GOVERNOR | 1 | |
| 9M6302 | 17 WASHER-SPECIAL | 2 | |
| 1146306 | 18 PIN-DOWEL | 1 | |
| 1146305 | 19 WASHER-SPRING | 1 | |
| 3K0810 | 20 RING-LOCK | 1 | |
| 7M7219 | 21 BEARING-THRUST | 1 | |
| 7M7193 | 22 RACE-THRUST BEARING | 2 | |
| 2P8630 | 23 DOWEL | 1 | |
| 1W4640 | 24 SEAT-SPRING | 1 | |
| 1W1132 | 25 WEIGHT AS-GOVERNOR | 1 | |
| 1S5440 | 26 DOWEL | 2 | |
| 1A9579 | 27 BOLT (5/16-18X1.5-IN) | 1 | |
| 1H5514 | 28 BOLT (5/16-18X1.625-IN) | 6 | |
| 9S5393 | 29 PLUG | 1 | |
| 2P8763 | GASKET | 1 | |
| 2B2695 | 30 BOLT (5/16-18X0.875-IN) | 1 | |
| 9L9578 | 31 BOLT (5/16-18X1.5-IN) | 1 | |
| 1144811 | 32 SLEEVE-VALVE | 1 | |
| 7N7163 | 33 COVER | 1 | |
| 4B9747 | 34 WASHER (0.266X0.375X0.031-IN THK) | 1 | |
| 5P6945 | 35 BOLT (1/4-20X1.125-IN) | 1 | |
| 5L8992 | 36 COVER-ADJUSTMENT | 1 | |
| 5L8991 | 37 GASKET-COVER | 1 | |
| 0S1617 | 38 BOLT (5/16-18X0.75-IN) | 1 | |
| 2W1491 | 39 LEVER-CONTROL | 1 | |
| 4W7654 | 40 BOLT (1/4-28X1.25-IN) | 1 | |
| 7B8105 | 41 RING-LOCK | 1 | |
| 6N9339 | 42 GASKET-GOVERNOR HOUSING | 1 | |
| 0S1618 | 43 BOLT (5/16-18X1-IN) | 1 | |
| 0S1615 | 44 BOLT (1/4-20X0.75-IN) | 3 | |
| 9M6293 | 45 LOCK-CYLINDER | 1 | |
| 1464244 | 46 PISTON AS-SERVO | 1 | |
| 5P9757 | SEAL-O-RING | 1 | |
| 1S4741 | CYLINDER-SERVO | 1 | |
| 8N6977 | SLEEVE | 1 | |
| 2P8697 | 47 GASKET | 1 |
