System And Components
107-2395 IGNITION GP-GAS ENGINES/N 4FD1-UP
Group No: 107-2395
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7C9722 | 1 BRACKET | 2 | |
| 1072401 | 2 BRACKET AS | 1 | |
| 9F6445 | NUT-WELD (1/4-20-THD) | 1 | |
| 1072398 | 3 HARNESS AS-WIRING | 1 | |
| 4P8905 | 4 MAGNETO GP | 1 | |
| 9Y7361 | 5 BOOT | 6 | |
| 4W2256 | 6 PLUG AS-SPARK | 6 | |
| 9Y4167 | 7 TRANSFORMER AS (IGNITION) | 6 | |
| 3T3622 | 8 CLAMP | 6 | |
| 8T6765 | 9 PLUG-PIPE (1/4-18-THD) | 1 | |
| 6V2671 | 10 CAP-PROTECTION | 1 | |
| 4P8134 | 11 CLIP (LADDER) | 6 | |
| 6V1196 | 12 SEAL-O-RING | 1 | |
| 9X6772 | 13 STRAP-CABLE | 6 | |
| 7X6034 | 14 STRAP AS-GROUND | 1 | |
| 8S8158 | 15 SEAL-WIRE | 7 | |
| 9M1974 | 16 WASHER-HARD (8.8X16X2-MM THK) | 5 | |
| 1C0569 | 17 BOLT (5/16-18X0.5-IN) | 3 | |
| 2H3755 | 18 BOLT (5/16-18X0.43-IN) | 2 | |
| 5P0537 | 19 WASHER-HARD (7.2X14.5X2-MM THK) | 3 | |
| 0S1616 | 20 BOLT (1/4-20X1-IN) | 1 | |
| 7B2742 | 21 BOLT (1/4-20X1.25-IN) | 1 | |
| 9S8750 | 22 NUT-FULL (1/4-20-THD) | 1 | |
| 1A2029 | 23 BOLT (3/8-16X1.125-IN) | 1 | |
| 5M2894 | 24 WASHER-HARD (10.2X18.5X2.5-MM THK) | 3 | |
| 0S1590 | 25 BOLT (3/8-16X2-IN) | 1 | |
| 0L1351 | 26 BOLT (3/8-16X0.875-IN) | 1 | |
| 0S0509 | 27 BOLT (3/8-16X0.75-IN) | 1 | |
| 5P1275 | 28 LOCKWIRE (.07M LG) | ||
| 9X6772 | 29 STRAP-CABLE | 5 | |
| 7E3060 | 30 ADAPTER | 1 | |
| 3E6488 | 31 PLUG AS-CONNECTOR | 1 |
