System And Components
109-8911 IGNITION GP-GAS ENGINES/N 4FD3377-UP
Group No: 109-8911
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P7581 | 1 CLIP (LADDER) | 3 | |
| 9X6772 | 2 STRAP-CABLE | 3 | |
| 2W3747 | 3 TRANSFORMER AS | 6 | |
| 7C9722 | 4 BRACKET | 2 | |
| 2502149 | 5 WIRE AS | 6 | |
| 7E0079 | 6 SEAL | 6 | |
| 2N2839 | 7 PLUG AS-SPARK | 6 | |
| 1083515 | GASKET-PLUG | 1 | |
| 8T6765 | 8 PLUG-PIPE (1/4-18-THD) | 1 | |
| 9M1974 | 9 WASHER-HARD (8.8X16X2-MM THK) | 11 | |
| 1C0569 | 10 BOLT (5/16-18X0.5-IN) | 11 | |
| 1A2029 | 11 BOLT (3/8-16X1.125-IN) | 2 | |
| 3288387 | 12 MAGNETO GP | 1 | |
| 9X6458 | 13 WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 1217552 | 14 HARNESS AS-WIRING | 1 | |
| 5P6627 | 15 LOCKWIRE (0.1-M) | ||
| 6V1196 | 16 SEAL-O-RING | 1 | |
| 2146132 | 17 TUBE | 6 | |
| 5P8068 | 18 SEAL-O-RING | 6 |
