System And Components
272-2375 IGNITION GP-GAS ENGINES/N 4FD3643-UP
Group No: 272-2375
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3T3622 | 1 CLAMP | 6 | |
| 4B8407 | 2 GASKET-COPPER | 1 | |
| 4D1326 | 3 LOCKWASHER | 1 | |
| 4W2256 | 4 PLUG AS-SPARK | 6 | |
| 1083515 | GASKET-PLUG | 1 | |
| 1767748 | GASKET (SPARK PLUG) | 1 | |
| 9G2731 | 5 HOLDER AS-FUSE | 2 | |
| 7C9722 | 6 BRACKET | 2 | |
| 8T6342 | 7 TUBE-HEAT SHRINK (3.2-MM DIA)(8-CM) | ||
| 9Y7361 | 8 BOOT | 6 | |
| 1149224 | 9 SPACER (11.13X19.05X47-MM THK) | 4 | |
| 1166806 | 10 SENSOR GP-SPEED (TIMING) | 1 | |
| 2146132 | 11 TUBE | 6 | |
| 2152434 | 12 TRANSFORMER AS | 6 | |
| 2907079 | 13 HARNESS AS-ENGINE | 1 | |
| 6D8149 | PLUG AS-CONNECTOR (10-PIN) | 2 | |
| 3962240 | 14 HARNESS AS-POWER (IGNITION) | 1 | |
| 2H3755 | 15 BOLT (5/16-18X0.43-IN) | 5 | |
| 5P4116 | 16 WASHER-HARD (8.8X20.5X2-MM THK) | 5 | |
| 5P8068 | 17 SEAL-O-RING | 6 | |
| 8T6765 | 18 PLUG-PIPE (1/4-18-THD) | 1 | |
| 1636164 | 19 CONTROL GP-TIMING | 1 | |
| 1638070 | 20 HARNESS AS-WIRING (TIMING) | 1 | |
| 3E6488 | 21 PLUG AS-CONNECTOR | 1 | |
| 2S6024 | 22 FUSE (5-AMPERE) | 2 |
