System And Components
120-8876 TANK GP-WATER -COOLANT OVERFLOWType 2
Group No: 120-8876
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P0306 | 1 VALVE AS | 2 | |
| 4P2349 | 2 SEAL | 2 | |
| 4P2352 | 3 WASHER (19.844X26.59X0.794-MM THK) | 2 | |
| 5D1026 | 4 CLAMP-BAND | 1 | |
| 5M2894 | 5 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 6K9602 | 6 LATCH AS | 1 | |
| 6V5016 | 7 VALVE-BALL | 1 | |
| 9L5141 | 8 HOSE AS | 1 | |
| 1139476 | 9 TUBE AS | 1 | |
| 1139479 | 10 TANK AS | 1 | |
| 1153493 | 11 BRACKET | 2 | |
| 1153494 | 12 HOSE AS | 1 | |
| 5D1026 | CLAMP-BAND | 1 | |
| 6V8523 | HOSE (17-CM) | ||
| 1203970 | TUBE | 1 | |
| 1153581 | 13 TUBE AS | 1 | |
| 1159128 | 14 CAP-RESERVOIR (7-PSI) | 1 | |
| 1162396 | 15 SUPPORT AS | 1 | |
| 1162399 | 16 SUPPORT AS | 2 | |
| 1208879 | 17 TUBE AS | 1 | |
| 1438540 | 18 SENSOR GP-COOLANT LEVEL | 1 | |
| 0616737 | 19 UNION-FLARED | 1 | |
| 0L1351 | 20 BOLT (3/8-16X0.875-IN) | 8 | |
| 0S0509 | 21 BOLT (3/8-16X0.75-IN) | 9 | |
| 0T0102 | 22 BOLT (3/8-16X0.625-IN) | 4 | |
| 2M9780 | 23 SEAL-O-RING | 1 | |
| 2N3478 | 24 SCREW-MACHINE (10-24X0.375-IN) | 2 | |
| 3H5939 | 25 GASKET-HEAT EXCHANGER | 1 | |
| 8S8820 | 26 CLIP | 1 | |
| 9S8752 | 27 NUT-FULL (3/8-16-THD) | 5 |
