System And Components
113-7042 IGNITION GP-GAS ENGINEPART OF 113-8489 CONVERSION AR-IGNITION
Group No: 113-7042
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9Y0152 | 1 BRACKET | 4 | |
| 2B2695 | 2 BOLT (5/16-18X0.875-IN) | 8 | |
| 9M1974 | 3 WASHER-HARD (8.8X16X2-MM THK) | 32 | |
| 1137047 | 4 BRACKET | 1 | |
| 5M2894 | 5 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 2D7134 | 6 STRAP AS | 1 | |
| 7C6744 | 7 MAGNETO GP | 1 | |
| 6V1196 | 8 SEAL-O-RING | 1 | |
| 0S1594 | 9 BOLT (3/8-16X1-IN) | 3 | |
| 1365077 | 10 BOX AS-CONTROL | 1 | |
| 4P4222 | HARNESS AS | 1 | |
| 7E3222 | 11 MOUNT-FLEXIBLE | 4 | |
| 9S8750 | 12 NUT-FULL (1/4-20-THD) | 16 | |
| 5P0537 | 13 WASHER-HARD (7.2X14.5X2-MM THK) | 16 | |
| 1B7182 | 14 BOLT (5/16-18X1.25-IN) | 24 | |
| 8T3389 | 15 U-BOLT | 4 | |
| 6I4452 | 16 TRANSFORMER AS | 8 | |
| 6V2410 | 17 SCREW-WASHER HEAD | 8 | |
| 3P0650 | 18 SEAL-O-RING | 8 | |
| 4P3415 | 19 TUBE AS | 8 | |
| 5P8068 | 20 SEAL-O-RING | 8 | |
| 1234710 | 21 EXTENSION AS | 8 | |
| 1462588 | 22 SPARK PLUG | 8 | |
| 3L6836 | 23 SPACER (0.5X0.75X0.56-IN THK) | 8 | |
| 0T0768 | 24 BOLT (7/16-14X1.75-IN) | 8 | |
| 7C3294 | 25 RETAINER | 8 | |
| 5P6025 | 26 LOCKWIRE | ||
| 1S1015 | 27 CLIP (LOOP) | 4 | |
| 1137044 | 28 HARNESS AS | 1 | |
| 0S1571 | 29 BOLT (3/8-16X1.75-IN) | 2 | |
| 9S8752 | 30 NUT-FULL (3/8-16-THD) | 4 | |
| 9M6527 | 31 WASHER-HARD (10.2X25.5X5-MM THK) | 3 | |
| 3S2093 | 32 STRAP-CABLE | 4 | |
| 3B1915 | 33 BOLT (3/8-16X1.375-IN) | 2 | |
| 7X6034 | 34 STRAP AS-GROUND | 1 | |
| 4S5719 | 35 SPACER (10.31X25X12.7-MM THK) | 4 | |
| 0S1588 | 36 BOLT (3/8-16X1.25-IN) | 2 | |
| 9Y6792 | GASKET-SPARK PLUG | 16 |
