System And Components
7C-0480 IGNITION GP-GAS ENGINES/N 2JF1-352
Group No: 7C-0480
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7C0485 | 1 HARNESS AS-ENGINE | 1 | |
| 3S8664 | 2 CLIP | 4 | |
| 5P8068 | 3 SEAL-O-RING | 8 | |
| 4S1962 | 4 CLIP (LOOP) | 2 | |
| 1462588 | 5 SPARK PLUG | 12 | |
| 9Y6792 | GASKET-SPARK PLUG | 1 | |
| 7N5667 | 6 BRACKET | 6 | |
| 6V1196 | 7 SEAL-O-RING | 1 | |
| 9M6527 | 8 WASHER-HARD (10.2X25.5X5-MM THK) | 3 | |
| 5M2894 | 9 WASHER-HARD (10.2X18.5X2.5-MM THK) | 13 | |
| 7C6744 | 10 MAGNETO GP | 1 | |
| 0S1620 | 11 BOLT (1/2-13X0.75-IN) | 5 | |
| 5P8245 | 12 WASHER-HARD (13.5X25.5X3-MM THK) | 5 | |
| 5P4295 | 13 CLIP | 3 | |
| 8M2769 | 14 CLIP | 2 | |
| 1234710 | 15 EXTENSION AS | 8 | |
| 1251372 | SEAL-O-RING | 1 | |
| 1A2029 | 16 BOLT (3/8-16X1.125-IN) | 9 | |
| 9S8752 | NUT-FULL (3/8-16-THD) | 6 | |
| 2B2695 | 17 BOLT (5/16-18X0.875-IN) | 12 | |
| 9M1974 | 18 WASHER-HARD (8.8X16X2-MM THK) | 36 | |
| 1B7182 | 19 BOLT (5/16-18X1.25-IN) | 24 | |
| 7W4377 | 20 TRANSFORMER | 8 | |
| 9Y5885 | 21 PLUG AS | 1 | |
| 7W5215 | 22 GASKET | 8 | |
| 3P0650 | 23 SEAL-O-RING | 8 | |
| 4W1661 | 24 TUBE | 8 | |
| 0T0320 | 25 BOLT (7/16-14X1.25-IN) | 8 | |
| 5P8244 | WASHER-HARD (12X22.5X2.5-MM THK) | 8 | |
| 7C3294 | 26 RETAINER | 8 | |
| 7W6892 | 27 ROD-SUPPORT | 2 | |
| 9L9132 | 28 WASHER-HARD (10.2X25.5X2.5-MM THK) | 1 | |
| 8M2773 | 29 CLIP (LOOP) | 1 | |
| 6B0933 | 30 SPACER (10.31X19.05X6.35-MM THK) | 1 | |
| 0L1143 | 31 BOLT (3/8-16X2.5-IN) | 1 |
