System And Components
9Y-0149 IGNITION GP-GAS ENGINEType 1
Group No: 9Y-0149
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9Y0152 | 1 BRACKET | 6 | |
| 2B2695 | 2 BOLT (5/16-18X0.875-IN) | 12 | |
| 9M1974 | 3 WASHER-HARD (8.8X16X2-MM THK) | 36 | |
| 9S8750 | 4 NUT-FULL (1/4-20-THD) | 24 | |
| 5M2894 | 5 WASHER-HARD (10.2X18.5X2.5-MM THK) | 9 | |
| 6V1196 | 6 SEAL-O-RING | 1 | |
| 0S1594 | 7 BOLT (3/8-16X1-IN) | 3 | |
| 7W2172 | 8 MAGNETO GP | 1 | |
| 5P0537 | 9 WASHER-HARD (7.2X14.5X2-MM THK) | 24 | |
| 1B7182 | 10 BOLT (5/16-18X1.25-IN) | 24 | |
| 8T3389 | 11 U-BOLT | 12 | |
| 9Y0155 | 12 HARNESS AS-WIRING | 1 | |
| 7W4377 | 13 TRANSFORMER | 8 | |
| 6V2410 | 14 SCREW-WASHER HEAD | 8 | |
| 3P0650 | 15 SEAL-O-RING | 8 | |
| 4P3415 | 16 TUBE AS | 8 | |
| 5P8068 | 17 SEAL-O-RING | 8 | |
| 9Y7042 | 18 EXTENSION AS | 8 | |
| 1064128 | 19 SPARK PLUG | 8 | |
| 3L6836 | 20 SPACER (0.5X0.75X0.56-IN THK) | 8 | |
| 0T0768 | 21 BOLT (7/16-14X1.75-IN) | 8 | |
| 7C3294 | 22 RETAINER | 8 | |
| 0L1351 | 23 BOLT (3/8-16X0.875-IN) | 2 | |
| 0S1588 | 24 BOLT (3/8-16X1.25-IN) | 1 | |
| 5P6025 | 25 LOCKWIRE (1M) | ||
| 1S1015 | 26 CLIP (LOOP) | 5 | |
| 5P8245 | 27 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 7B3235 | 28 BOLT (1/2-13X1.375-IN) | 3 | |
| 9S8752 | 29 NUT-FULL (3/8-16-THD) | 2 | |
| 7C0726 | 30 FILM | 8 | |
| 7E0875 | 31 BRACKET | 1 | |
| 9Y9549 | 32 PLATE | 1 |
