364-3477 CYLINDER HEAD GPS/N 1RK124-UP

Group No: 364-3477
Part NumberPart NameQty
2A44291 LOCK-RETAINER48
2N71742 GASKET6
4N59063 SPRING-VALVE24
6N71544 ROTOCOIL AS24
21209365 SEAT-VALVE (EXHAUST)12
2934801SEAT-VALVE (0.127-MM OS, EXHAUST)
2934802SEAT-VALVE (0.25-MM OS, EXHAUST)
2934803SEAT-VALVE (0.381-MM OS, EXHAUST)
2934804SEAT-VALVE (0.508-MM OS, EXHAUST)
2934805SEAT-VALVE (0.76-MM OS, EXHAUST)
21375366 GUIDE-VALVE (INLET)12
2936535GUIDE-VALVE (0.127-MM OS, INLET)
2936536GUIDE-VALVE (0.25-MM OS, INLET)
2936537GUIDE-VALVE (0.508-MM OS, INLET)
21375377 GUIDE-VALVE (EXHAUST)12
2935841GUIDE-VALVE (0.127-MM OS, EXHAUST)
2935842GUIDE-VALVE (0.25-MM OS, EXHAUST)
2935843GUIDE-VALVE (0.508-MM OS, EXHAUST)
21375398 ADAPTER6
21432869 SEAT-VALVE (INLET)12
2934632SEAT-VALVE (0.127-MM OS, INLET)
2934633SEAT-VALVE (0.25-MM OS, INLET)
2934634SEAT-VALVE (0.381-MM OS, INLET)
2934635SEAT-VALVE (0.508-MM OS, INLET)
2934636SEAT-VALVE (0.76-MM OS, INLET)
3498417SEAT-VALVE (INLET)(SHORT)
3498423SEAT-VALVE (0.254-MM OS, INLET)(SHORT)
3498424SEAT-VALVE (0.508-MM OS, INLET)(SHORT)
3498425SEAT-VALVE (SHORT)
223651810 CYLINDER HEAD AS1
3B0623PLUG-CUP10
3B0645PLUG-CUP (32.08-MM OD)12
8T6762PLUG-PIPE (1/2-14-THD)4
8T6767PLUG-PIPE (3/8-18-THD)1
483270911 VALVE-INLET12
483271012 VALVE-EXHAUST12
109007313 SEAL-O-RING6
444644414 SEAL AS-VALVE12
