System And Components
168-4408 AFTERCOOLER GP-WATERS/N 4EK2412-UP
Group No: 168-4408
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1213339 | 1 SUPPORT | 1 | |
| 1229785 | 2 BRACKET | 1 | |
| 1285423 | 3 HOUSING (AFTERCOOLER)(FRONT) | 1 | |
| 1285424 | 4 HOUSING (AFTERCOOLER)(REAR) | 1 | |
| 1285425 | 5 PLATE | 1 | |
| 1286836 | 6 FLANGE | 1 | |
| 1525705 | 7 GASKET | 2 | |
| 1739765 | 8 AFTERCOOLER GP-RAW WATER | 1 | |
| 1776911 | 9 SEAL-O-RING | 1 | |
| 0L1143 | 10 BOLT (3/8-16X2.5-IN) | 4 | |
| 0S1590 | 11 BOLT (3/8-16X2-IN) | 4 | |
| 1A2029 | 12 BOLT (3/8-16X1.125-IN) | 8 | |
| 1T0720 | 13 BOLT-12 POINT HEAD (3/8-16X1.25-IN) | 72 | |
| 3B1915 | 14 BOLT (3/8-16X1.375-IN) | 6 | |
| 5M2894 | 15 WASHER-HARD (10.2X18.5X2.5-MM THK) | 10 | |
| 5P7701 | 16 SEAL-O-RING | 1 | |
| 7W6492 | 17 PLUG-PIPE (1/2-14-THD) | 1 | |
| 7X4810 | 18 SEAL-O-RING | 2 | |
| 8L2786 | 19 SEAL-O-RING | 4 | |
| 8T6765 | 20 PLUG-PIPE (1/4-18-THD) | 4 | |
| 9L9132 | 21 WASHER-HARD (10.2X25.5X2.5-MM THK) | 18 | |
| 9S4181 | 22 PLUG (1-5/16-12-THD) | 1 | |
| 9S4185 | 23 PLUG (3/4-16-THD) | 4 | |
| 9S8752 | 24 NUT-FULL (3/8-16-THD) | 10 | |
| 9X6138 | 25 PLUG-PIPE | 1 |
