System And Components
104-3175 BOX GP-CONTROL PANELS/N 4EK1-34
Group No: 104-3175
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P9572 | 1 BOX GP-CONTROL PANEL | 1 | |
| 2W8798 | 2 SWITCH AS-PUSH BUTTON (EMERGENCY STOP) | 1 | |
| 2W8603 | 3 MOUNT-FLEXIBLE | 8 | |
| 1036267 | 4 FILM-INSTRUMENT PANEL | 1 | |
| 2W8683 | 5 BLOCK-CONTACT | 1 | |
| 4P9573 | 6 HARNESS AS-WIRING (SERVICE TOOL) | 1 | |
| 3E0105 | 7 MOUNT | 2 | |
| 8L8413 | 8 STRAP-CABLE (WHITE) | 2 | |
| 4P9574 | 9 HARNESS AS-WIRING (EMERGENCY STOP) | 1 | |
| 5S4245 | 10 SCREW-MACHINE (4-40X0.5-IN) | 4 | |
| 6B4540 | 11 NUT (4-40-THD) | 4 | |
| 3N2050 | 12 FUSE (15-AMPERE) | 2 | |
| 5N5537 | 13 BLOCK-FUSE | 1 | |
| 7R3029 | 14 CAP-DUST | 1 | |
| 9X9675 | 15 BRACKET-END | 4 | |
| 9X9676 | 16 TERMINAL | 33 | |
| 3E0355 | 17 BLOCK-FUSE | 1 | |
| 3E5502 | 18 TERMINAL (SINGLE) | 2 | |
| 9X9677 | 19 COVER-END | 2 | |
| 9X9616 | 20 COVER-END | 4 | |
| 9X9614 | 21 TERMINAL (SINGLE) | 4 | |
| 3B4501 | 22 LOCKWASHER | 32 | |
| 6D5801 | 23 LOCKNUT (8-32-THD) | 32 | |
| 1G6660 | 24 CONNECTOR-CORD | 3 | |
| 0683708 | 25 LOCKNUT (1-11-1/4-THD) | 3 | |
| 7S1201 | 26 SCREW-MACHINE (8-32X0.375-IN) | 32 | |
| 6B4542 | 27 LOCKWASHER | 4 | |
| 9X9615 | 28 TERMINAL (SINGLE) | 13 | |
| 3E5503 | 29 BAR-FIXED BRIDGE | 2 | |
| 3E5504 | 30 BAR-FIXED BRIDGE | 1 | |
| 3E2286 | 31 STRIP-CONTACT | 1 | |
| 7L6479 | 32 PLUG-BUTTON | 5 |
