System And Components
247-7996 BOX GP-JUNCTIONPART OF 149-8735 BOX GP-JUNCTION, 130-7383 IGNITION GP-GAS ENGINE
Group No: 247-7996
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9D2868 | 1 LENS-RED | 1 | |
| 9D2867 | 2 LENS-AMBER | 1 | |
| 9D9161 | 3 LENS-GREEN | 1 | |
| 1096507 | 4 SWITCH AS-PUSH BUTTON (EMERGENCY STOP) | 1 | |
| 1112111 | 5 GUARD | 1 | |
| 7N5876 | 6 LAMP (24-VOLT, 0.2-AMPERE)(CLEAR) | 3 | |
| 9D3127 | 7 BASE AS-INDICATOR LIGHT | 3 | |
| 6V8367 | LOCKWASHER | 1 | |
| 6V8382 | NUT-HEX (11/16-27-THD) | 1 | |
| 1307364 | 8 CIRCUIT BREAKER AS (15-AMPERE) | 1 | |
| 9D3721 | 9 SWITCH-TOGGLE (SINGLE POLE)(DIAGNOSTIC RESET) | 1 | |
| 1111324 | 10 BLOCK-CONTACT (1-POLE) | 1 | |
| 8C8560 | 11 SCREW-LOCK (4-40X0.5-IN) | 24 | |
| 1328485 | 12 NUT-RING | 2 | |
| 1328486 | 13 NUT-RING | 2 | |
| 1310765 | 14 GUARD | 1 | |
| 2477994 | 15 JUNCTION BOX | 1 | |
| 1309463 | 16 FILM-CONTROL PANEL (EIS) | 1 | |
| 2477995 | 17 HARNESS AS-BOX | 1 | |
| 1314883 | 18 PLUG AS-CONNECTOR | 1 | |
| 1314889 | 19 GASKET | 2 | |
| 1314888 | 20 GASKET | 1 | |
| 7R3029 | 21 CAP-DUST | 1 | |
| 1314887 | 22 GASKET | 2 | |
| 1314890 | 23 GASKET | 1 | |
| 2339517 | 24 GASKET | 1 | |
| 3H3627 | 25 SCREW-MACHINE (8-32X0.625-IN) | 4 | |
| 1313906 | 26 PLUG AS-CONNECTOR | 1 | |
| 3E6493 | PLUG AS-CONNECTOR | 1 | |
| 5P5623 | WIRE-ELECTRICAL (16-GA, BLACK)(0.1-M) | ||
| 3E5165 | 27 CAP AS-PROTECTION | 1 | |
| 2339228 | 28 PLUG-SEAL | 5 | |
| 1243176 | 29 COVER | 1 | |
| 4B2043 | 30 NUT (8-32-THD) | 4 | |
| 1328487 | 31 NUT-RING | 1 | |
| 1328488 | 32 NUT-RING | 1 | |
| 0966166 | 33 WASHER-HARD (4.5X9X1-MM THK) | 8 | |
| 1071351 | 34 CONNECTOR-FLEXIBLE | 1 | |
| 4P4894 | 35 SEAL | 1 | |
| 1355011 | 36 CAP | 2 | |
| 5P1276 | 37 CONDUIT (26.5-MM ID)(30-CM) | ||
| 1123235 | 38 ADAPTER-FLEXIBLE | 1 | |
| 2479600 | 39 PLUG AS | 1 |
